Dayton Timing Pulley: Trapezoidal, Plain, For T10 Timing Belt Section, For 25 mm Belt Wd - T10 Section Timing Belt Pulleys
DaytonT10 Section Timing Belt Pulleys

Dayton Timing Pulley: Trapezoidal, Plain, For T10 Timing Belt Section, For 25 mm Belt Wd

The DAYTON Timing Pulley is a T10 Section Timing Belt Pulley with a trapezoidal tooth profile and a plain finish. It is designed for a 25 mm belt width and features 24 teeth, as indicated by the manufacturer part…

SKU 3G-OTH-105500

Brand
Dayton
Item
Timing Pulley: Trapezoidal, Plain, For T10 Timing Belt Section, For 25 mm Belt Wd
Category
T10 Section Timing Belt Pulleys
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
40T10/24-2
Type
Plain, For T10 Timing Belt Section, For 25 mm Belt Wd
Teeth
24
Finish
Plain
Tooth Profile
Trapezoidal
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a T10 Section Timing Belt Pulley with a trapezoidal tooth profile and a plain finish. It is designed for a 25 mm belt width and features 24 teeth, as indicated by the manufacturer part number 40T10/24-2.

Frequently Asked Questions

What is the DAYTON Timing Pulley 40T10/24-2 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit rotary motion and torque without slippage. It is ideal for industrial machinery, conveyor systems, and automation equipment requiring precise timing and positioning with a T10 belt section and 25 mm belt width.

What are the specifications of the DAYTON Timing Pulley 40T10/24-2?

The DAYTON Timing Pulley has a trapezoidal tooth profile, plain finish, and 24 teeth. It is designed for a T10 timing belt section and a 25 mm belt width. The manufacturer part number is 40T10/24-2. This pulley is suitable for applications requiring positive drive and accurate indexing.

Where to buy the DAYTON Timing Pulley 40T10/24-2 worldwide?

You can source the DAYTON Timing Pulley 40T10/24-2 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this T10 section pulley.

How to select the correct DAYTON timing pulley for a T10 belt?

To select the correct DAYTON timing pulley, match the tooth profile (trapezoidal), belt section (T10), and belt width (25 mm). Verify the number of teeth (24 for this model) and the bore size required for your shaft. Ensure the pulley finish (plain) suits your environment. Consult the manufacturer part number 40T10/24-2 for exact specifications.
