Dayton Timing Pulley: Trapezoidal, Plain, For T5 Timing Belt Section, For 16 mm Belt Wd - T5 Section Timing Belt Pulleys
DaytonT5 Section Timing Belt Pulleys

Dayton Timing Pulley: Trapezoidal, Plain, For T5 Timing Belt Section, For 16 mm Belt Wd

The DAYTON Timing Pulley is a T5 Section Timing Belt Pulley with a trapezoidal tooth profile and a plain finish. It is designed for use with a 16 mm belt width and features 10 teeth, identified by manufacturer part…

SKU 3G-OTH-103233

Brand
Dayton
Item
Timing Pulley: Trapezoidal, Plain, For T5 Timing Belt Section, For 16 mm Belt Wd
Category
T5 Section Timing Belt Pulleys
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
27T5/10-2
Type
Plain, For T5 Timing Belt Section, For 16 mm Belt Wd
Teeth
10
Finish
Plain
Tooth Profile
Trapezoidal
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a T5 Section Timing Belt Pulley with a trapezoidal tooth profile and a plain finish. It is designed for use with a 16 mm belt width and features 10 teeth, identified by manufacturer part number 27T5/10-2.

Frequently Asked Questions

What is the DAYTON T5 timing pulley used for?

The DAYTON T5 timing pulley is used in precision motion-control systems such as CNC routers, packaging machinery, and conveyor drives. Its trapezoidal tooth profile and 10 teeth provide positive engagement with T5 timing belts for synchronous power transmission.

What are the specifications of the DAYTON 27T5/10-2 timing pulley?

The DAYTON 27T5/10-2 timing pulley has a trapezoidal tooth profile, plain finish, 10 teeth, and is designed for a 16 mm wide T5 timing belt. It is a plain-bore pulley, meaning it requires custom machining for shaft mounting.

Where to buy DAYTON timing pulleys worldwide?

3G Electric supplies DAYTON timing pulleys worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on the 27T5/10-2 pulley.

How to select the right T5 timing pulley for a 16 mm belt?

To select the correct T5 timing pulley for a 16 mm belt, match the belt width and tooth profile. The DAYTON 27T5/10-2 has 10 teeth and a trapezoidal profile. Ensure the pulley bore size matches your shaft; plain-bore pulleys require drilling or reaming.
