Dayton Blower with Drive Package: 16 1/2 in Wheel Dia, Belt Drive, Includes Drive Pack - Belt-Drive Blowers with Drive
DaytonBelt-Drive Blowers with Drive

Dayton Blower with Drive Package: 16 1/2 in Wheel Dia, Belt Drive, Includes Drive Pack

The Dayton 43XH04 is a belt-drive blower with drive package, featuring a 16 1/2 in wheel diameter and a 1 hp motor. It delivers 3,480 cfm, operates at 230/460V AC, and has a CW rotation with an open motor housing design.

SKU 3G-OTH-76092

Brand
Dayton
Item
Blower with Drive Package: 16 1/2 in Wheel Dia, Belt Drive, Includes Drive Pack
Category
Belt-Drive Blowers with Drive
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
43XH04
Type
Belt Drive, Includes Drive Pack, 3,480 cfm, 1 hp
Rotation
CW
Nominal Voltage
230/460V AC
Motor Housing Design
Open Motor
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 43XH04 is a belt-drive blower with drive package, featuring a 16 1/2 in wheel diameter and a 1 hp motor. It delivers 3,480 cfm, operates at 230/460V AC, and has a CW rotation with an open motor housing design.

Frequently Asked Questions

What is the Dayton 43XH04 blower used for?

The Dayton 43XH04 belt-drive blower with drive package is used for industrial ventilation, material handling, and air movement in factories, warehouses, and commercial buildings. It delivers 3,480 cfm at 1 hp, making it suitable for exhausting fumes, dust, or heat in medium-duty applications.

What are the specifications of the Dayton 43XH04?

The Dayton 43XH04 has a 16 1/2 in wheel diameter, belt drive with drive pack, 1 hp motor, and 3,480 cfm airflow. It operates at 230/460V AC with CW rotation and an open motor housing design. The manufacturer part number is 43XH04.

Where to buy the Dayton 43XH04 worldwide?

3G Electric supplies the Dayton 43XH04 belt-drive blower worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the Dayton 43XH04 blower?

Install the Dayton 43XH04 on a stable, level surface with proper clearance for airflow. Ensure electrical supply matches 230/460V AC and rotation is CW. Use flexible duct connections to reduce vibration. Follow Dayton's manual for belt tensioning and drive alignment.
