Dayton Guard-Mounted Exhaust Fan: 24 in Blade, 1/3 hp, Totally Enclosed Air Over - Guard-Mount Exhaust Fans
DaytonGuard-Mount Exhaust Fans

Dayton Guard-Mounted Exhaust Fan: 24 in Blade, 1/3 hp, Totally Enclosed Air Over

The DAYTON Guard-Mounted Exhaust Fan (SKU 484X57) is a 24-inch blade guard-mount exhaust fan with a 1/3 hp motor, delivering 4,565 cfm. It features a Totally Enclosed Air Over motor enclosure and operates on 115V AC…

SKU 3G-OTH-81342

Brand
Dayton
Item
Guard-Mounted Exhaust Fan: 24 in Blade, 1/3 hp, Totally Enclosed Air Over
Category
Guard-Mount Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
484X57
Type
1/3 hp, Totally Enclosed Air Over, 4,565 cfm
AC
115V
Motor Enclosure
Totally Enclosed Air Over
Nameplate Voltage
115V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Guard-Mounted Exhaust Fan (SKU 484X57) is a 24-inch blade guard-mount exhaust fan with a 1/3 hp motor, delivering 4,565 cfm. It features a Totally Enclosed Air Over motor enclosure and operates on 115V AC nameplate voltage.

Frequently Asked Questions

What is the DAYTON Guard-Mounted Exhaust Fan used for?

The DAYTON Guard-Mounted Exhaust Fan is used for general ventilation and air exhaust in industrial and commercial facilities. It helps remove heat, fumes, and stale air from workshops, warehouses, and manufacturing areas. The guard-mount design allows direct installation into walls or openings for efficient airflow.

What are the specifications of the DAYTON Guard-Mounted Exhaust Fan 484X57?

The DAYTON Guard-Mounted Exhaust Fan model 484X57 has a 24-inch blade, a 1/3 hp motor, and delivers 4,565 cfm. It features a Totally Enclosed Air Over motor enclosure and operates on 115V AC nameplate voltage. The fan is designed for reliable performance in demanding industrial environments.

Where to buy the DAYTON Guard-Mounted Exhaust Fan worldwide?

You can source the DAYTON Guard-Mounted Exhaust Fan 484X57 through 3G Electric, a global industrial equipment distributor. 3G Electric handles full logistics, customs clearance, and delivery to worldwide destinations. Contact them for availability and lead time on this DAYTON fan.

How to install a guard-mounted exhaust fan?

To install a guard-mounted exhaust fan like the DAYTON 484X57, mount the fan securely into a wall opening or frame using the provided guard. Ensure the electrical supply matches the nameplate voltage (115V AC). Connect wiring per local codes and verify the fan is properly grounded before operation.
