Dayton Rotary Gear Pump Head: Magnetic Drive, Bronze Body, 1" FNPT, 20.5 gpm - Pedestal-Mount Rotary Gear Pumps
DaytonPedestal-Mount Rotary Gear Pumps

Dayton Rotary Gear Pump Head: Magnetic Drive, Bronze Body, 1" FNPT, 20.5 gpm

The DAYTON Rotary Gear Pump Head: Magnetic Drive is a pedestal-mount rotary gear pump with a bronze body and 1" FNPT ports. It includes a relief valve and features a stainless steel shaft, delivering a flow rate of…

SKU 3G-OTH-93242

Brand
Dayton
Item
Rotary Gear Pump Head: Magnetic Drive, Bronze Body, 1" FNPT, 20.5 gpm
Category
Pedestal-Mount Rotary Gear Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4KHF6
Type
Bronze Body, 20.5 gpm, SS Shaft Material
FNPT
1"
Ports
1" FNPT
Includes Relief Valve
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Rotary Gear Pump Head: Magnetic Drive is a pedestal-mount rotary gear pump with a bronze body and 1" FNPT ports. It includes a relief valve and features a stainless steel shaft, delivering a flow rate of 20.5 gpm (MPN 4KHF6).

Frequently Asked Questions

What is the DAYTON Rotary Gear Pump Head 4KHF6 used for?

The DAYTON Rotary Gear Pump Head 4KHF6 is a pedestal-mount magnetic drive pump used for transferring clean, non-abrasive fluids in industrial applications. Its bronze body and stainless steel shaft make it suitable for water, oils, and mild chemicals. The integral relief valve protects the system from overpressure.

What are the specifications of the DAYTON 4KHF6 gear pump?

The DAYTON 4KHF6 is a magnetic drive rotary gear pump head with a bronze body, 1" FNPT ports, and a stainless steel shaft. It delivers 20.5 gpm and includes a relief valve. The manufacturer part number is 4KHF6. It is designed for pedestal-mount installation.

Where to buy the DAYTON 4KHF6 gear pump worldwide?

3G Electric supplies the DAYTON 4KHF6 rotary gear pump head worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this pump to support your operations.

How to install the DAYTON 4KHF6 magnetic drive gear pump?

Mount the DAYTON 4KHF6 pump on a rigid base, align the coupling to the driver shaft, and connect 1" FNPT piping. Ensure the magnetic drive is free of debris. Prime the pump before startup. Follow generic best practices for rotary gear pumps: avoid dry running and check relief valve function.
