Dayton Class 2 Transformer: 40 VA Power Rating, 120V AC, 24V AC, Primary Fuse - Open Class 2 Transformers
DaytonOpen Class 2 Transformers

Dayton Class 2 Transformer: 40 VA Power Rating, 120V AC, 24V AC, Primary Fuse

The DAYTON Class 2 Transformer (SKU 4VZE5) is an open-style transformer with a 40 VA power rating. It features a foot mounting configuration, 120V AC input and 24V AC output, with wire lead connections on both…

SKU 3G-OTH-47623

Brand
Dayton
Item
Class 2 Transformer: 40 VA Power Rating, 120V AC, 24V AC, Primary Fuse
Category
Open Class 2 Transformers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4VZE5
Type
Primary Fuse, Foot/Plate, Wire Lead
AC
120V
Mounting
Foot
Input Voltage
120V AC
Output Voltage
24V AC
Connection - Primary
Wire Lead
Connection - Secondary
Wire Lead
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Class 2 Transformer (SKU 4VZE5) is an open-style transformer with a 40 VA power rating. It features a foot mounting configuration, 120V AC input and 24V AC output, with wire lead connections on both primary and secondary sides.

Frequently Asked Questions

What is a DAYTON Class 2 Transformer used for?

A DAYTON Class 2 Transformer like the 4VZE5 steps down 120V AC input to 24V AC output for low-voltage control circuits. It is commonly used in HVAC systems, lighting controls, doorbells, and industrial automation to power relays, contactors, and programmable logic controllers safely.

What are the specifications of the DAYTON 4VZE5 transformer?

The DAYTON 4VZE5 is a 40 VA open-style Class 2 transformer with 120V AC input and 24V AC output. It features wire lead connections on both primary and secondary sides, a foot mounting plate, and a primary fuse. This model is designed for reliable low-voltage power in control applications.

Where to buy a DAYTON Class 2 Transformer worldwide?

3G Electric supplies the DAYTON Class 2 Transformer 4VZE5 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this open-style 40 VA transformer.

How to install a DAYTON Class 2 Transformer?

Mount the DAYTON 4VZE5 securely using its foot plate in a dry, ventilated location. Connect the primary wire leads to a 120V AC supply and the secondary leads to your 24V AC load. Always verify the primary fuse is correctly rated and follow local electrical codes for safe installation.
