Dayton Gearmotor: Parallel, Single Output Shaft, PSC, TEFC, 70 RPM, 61 in-lb Max Torque - Parallel Shaft AC Gearmotors
DaytonParallel Shaft AC Gearmotors

Dayton Gearmotor: Parallel, Single Output Shaft, PSC, TEFC, 70 RPM, 61 in-lb Max Torque

The DAYTON AC Gearmotor: Parallel (SKU 4Z521) is a parallel shaft AC gearmotor with a single output shaft, PSC motor, and TEFC enclosure. It operates at 70 RPM with a maximum torque of 61 in-lb and is reversible…

SKU 3G-OTH-122723

Brand
Dayton
Item
Gearmotor: Parallel, Single Output Shaft, PSC, TEFC, 70 RPM, 61 in-lb Max Torque
Category
Parallel Shaft AC Gearmotors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4Z521
Type
Single Output Shaft, PSC, TEFC, 70 RPM, 61 in-lb Max Torque, CW/CCW
Inverter Rated
No
Full Load Current
1.2/0.63 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON AC Gearmotor: Parallel (SKU 4Z521) is a parallel shaft AC gearmotor with a single output shaft, PSC motor, and TEFC enclosure. It operates at 70 RPM with a maximum torque of 61 in-lb and is reversible (CW/CCW). This unit is not inverter rated and has a full load current of 1.2/0.63 A.

Frequently Asked Questions

What is the DAYTON AC Gearmotor 4Z521 used for?

The DAYTON AC Gearmotor 4Z521 is a parallel shaft gearmotor used in industrial automation, conveyors, and material handling. Its 70 RPM output and 61 in-lb torque suit light-duty positioning and drive applications requiring reversible (CW/CCW) operation.

What are the specifications of the DAYTON AC Gearmotor 4Z521?

The DAYTON AC Gearmotor 4Z521 is a parallel shaft unit with a single output shaft, PSC motor, and TEFC enclosure. It delivers 70 RPM, 61 in-lb maximum torque, and draws 1.2/0.63 A full load current. It is not inverter rated and operates CW/CCW.

Where to buy the DAYTON AC Gearmotor 4Z521 worldwide?

3G Electric supplies the DAYTON AC Gearmotor 4Z521 to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time; we source genuine DAYTON parts across 14 industrial departments.

How to select a parallel shaft AC gearmotor like the DAYTON 4Z521?

When selecting a parallel shaft AC gearmotor, match output speed (70 RPM) and torque (61 in-lb) to your load. Verify enclosure (TEFC for dusty environments), motor type (PSC for constant speed), and reversibility (CW/CCW). Confirm current draw (1.2/0.63 A) matches your power supply.
