Dayton Gearmotor: Parallel, 24V DC, TENV, 1.3 RPM, 50 in-lb Max Torque - Parallel Shaft Subfractional DC Gearmotors
DaytonParallel Shaft Subfractional DC Gearmotors

Dayton Gearmotor: Parallel, 24V DC, TENV, 1.3 RPM, 50 in-lb Max Torque

The DAYTON DC Gearmotor: Parallel is a parallel shaft subfractional DC gearmotor from DAYTON. It features a permanent magnet DC motor type, operates at 24V DC with a full load current of 0.16 A, and delivers 1.3 RPM…

SKU 3G-OTH-118301

Brand
Dayton
Item
Gearmotor: Parallel, 24V DC, TENV, 1.3 RPM, 50 in-lb Max Torque
Category
Parallel Shaft Subfractional DC Gearmotors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
52JE55
Type
TENV, 1.3 RPM, 50 in-lb Max Torque
DC
24V
Motor Type
Permanent Magnet DC
Input Horsepower
1/230 hp
Full Load Current
0.16 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON DC Gearmotor: Parallel is a parallel shaft subfractional DC gearmotor from DAYTON. It features a permanent magnet DC motor type, operates at 24V DC with a full load current of 0.16 A, and delivers 1.3 RPM with a maximum torque of 50 in-lb. The unit has a TENV enclosure and a 1/230 hp input horsepower rating.

Frequently Asked Questions

What is the DAYTON DC Gearmotor 52JE55 used for?

The DAYTON DC Gearmotor 52JE55 is used in low-speed, high-torque industrial applications such as conveyor drives, indexing tables, and material handling equipment. Its 24 VDC permanent magnet motor and 1.3 RPM output make it suitable for precise positioning and automated machinery where controlled motion is required.

What are the specifications of the DAYTON DC Gearmotor 52JE55?

The DAYTON DC Gearmotor 52JE55 is a parallel shaft subfractional gearmotor with a permanent magnet DC motor. It operates at 24 VDC, draws 0.16 A full load current, delivers 1.3 RPM, and provides 50 in-lb maximum torque. Input horsepower is 1/230 hp, and the enclosure is TENV. The manufacturer part number is 52JE55.

Where to buy the DAYTON DC Gearmotor 52JE55 worldwide?

You can source the DAYTON DC Gearmotor 52JE55 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine DAYTON components for industrial applications.

How to select the right DAYTON DC Gearmotor for an application?

To select the right DAYTON DC Gearmotor, match the required output speed and torque to the load. For the 52JE55, verify that 24 VDC power is available and that the 1.3 RPM and 50 in-lb torque meet your needs. Consider the TENV enclosure for dusty environments. Consult a DAYTON catalog or contact 3G Electric for guidance.
