Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water, 43,600 BtuH Output @ 200 F Water - Suspended Horizontal Hydronic Wall & Ceiling Unit Heaters
DaytonSuspended Horizontal Hydronic Wall & Ceiling Unit Heaters

Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water, 43,600 BtuH Output @ 200 F Water

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 5PV48) is a suspended horizontal unit heater designed for water heating systems. It delivers 43,600 BtuH output at 200°F water and 900 cfm airflow, with a 1-1/4…

SKU 3G-OTH-65594

Brand
Dayton
Item
Hydronic Wall and Ceiling Unit Heater: Steam/Water, 43,600 BtuH Output @ 200 F Water
Category
Suspended Horizontal Hydronic Wall & Ceiling Unit Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5PV48
Type
43,600 BtuH Output @ 200 F Water, 900 cfm
Air Flow
900 cfm
Fan Guard Type
OSHA Compliant Guard
Heating Method
Water
Overall Dimensions - H x W x D
20-1/2 in x 17-1/8 in x 10-15/16 in
Connection Size, Connection Type
1-1/4 in, Threaded Female NPT
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 5PV48) is a suspended horizontal unit heater designed for water heating systems. It delivers 43,600 BtuH output at 200°F water and 900 cfm airflow, with a 1-1/4 in threaded female NPT connection and an OSHA compliant fan guard. Its overall dimensions are 20-1/2 in H x 17-1/8 in W x 10-15/16 in D.

Frequently Asked Questions

What is the DAYTON hydronic wall and ceiling unit heater used for?

The DAYTON hydronic unit heater (5PV48) is used for space heating in commercial and industrial facilities. It circulates hot water through a coil to heat air, which is then distributed by a 900 cfm fan. Typical applications include warehouses, workshops, and loading docks.

What are the specifications of the DAYTON 5PV48 unit heater?

The DAYTON 5PV48 delivers 43,600 BtuH output at 200°F water with 900 cfm airflow. It has a 1-1/4 in threaded female NPT connection, an OSHA compliant fan guard, and measures 20-1/2 in H x 17-1/8 in W x 10-15/16 in D. It is a suspended horizontal hydronic unit heater.

Where to buy the DAYTON 5PV48 unit heater worldwide?

3G Electric supplies the DAYTON 5PV48 hydronic unit heater to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this item.

How to install a DAYTON hydronic wall and ceiling unit heater?

Install the DAYTON unit heater suspended horizontally from a ceiling or wall using the mounting brackets. Connect the 1-1/4 in threaded female NPT water supply and return lines. Ensure the fan guard is OSHA compliant and the unit is clear of obstructions. Follow local codes and the manufacturer's manual.
