Dayton Supplementary Protector: 2 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63 - B-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
DaytonB-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors

Dayton Supplementary Protector: 2 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63

The DAYTON IEC Supplementary Protector (SKU 5ZUX1) is a B-Curve, 2-Pole UL1077 DIN Rail-Mount supplementary protector rated at 2 A Amps. It features a Max. AIR Rating of 7.5kA at 480V AC, an AC Voltage Rating of 480V…

SKU 3G-OTH-21624

Brand
Dayton
Item
Supplementary Protector: 2 A Amps, 7.5kA at 480V AC, Screw Clamp, NDB2-63
Category
B-Curve, 2-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5ZUX1
Series
NDB2-63
Type
7.5kA at 480V AC, Screw Clamp, NDB2-63, B
AC
480V
Curve Type
B
Max. AIR Rating
7.5kA at 480V AC
AC Voltage Rating
480V AC
DC Voltage Rating
Not Rated
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON IEC Supplementary Protector (SKU 5ZUX1) is a B-Curve, 2-Pole UL1077 DIN Rail-Mount supplementary protector rated at 2 A Amps. It features a Max. AIR Rating of 7.5kA at 480V AC, an AC Voltage Rating of 480V AC, and a Screw Clamp terminal connection. This unit is part of the NDB2-63 series and is not rated for DC voltage.

Frequently Asked Questions

What is the DAYTON IEC Supplementary Protector 5ZUX1 used for?

The DAYTON IEC Supplementary Protector 5ZUX1 is used to protect industrial control circuits and equipment from overcurrent and short circuits. It is commonly applied in panel building, HVAC, and machinery control systems where a B-curve trip characteristic is needed for resistive or light inductive loads.

What are the specifications of the DAYTON 5ZUX1 supplementary protector?

The DAYTON 5ZUX1 is a 2-pole, B-curve supplementary protector rated at 2 A amps with a maximum AIR rating of 7.5kA at 480V AC. It has a screw clamp terminal connection, is part of the NDB2-63 series, and is UL1077 listed. DC voltage rating is not rated.

Where to buy the DAYTON 5ZUX1 supplementary protector worldwide?

You can source the DAYTON 5ZUX1 supplementary protector worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the DAYTON 5ZUX1 supplementary protector on a DIN rail?

To install the DAYTON 5ZUX1, snap it onto a standard 35mm DIN rail. Ensure the rail is clean and the protector is oriented correctly. Connect wires using the screw clamp terminals, tightening to the torque specified on the device label. Always de-energize the circuit before installation.
