Dayton Supply Fan w/Drive Package: Belt Drive, 48 in Blade, Open Dripproof, 19,995 cfm - Belt-Drive Panel Supply Fans with Drive Package
DaytonBelt-Drive Panel Supply Fans with Drive Package

Dayton Supply Fan w/Drive Package: Belt Drive, 48 in Blade, Open Dripproof, 19,995 cfm

The DAYTON Supply Fan w/Drive Package: Belt Drive (MPN 7AD11) is an unassembled belt-drive panel supply fan featuring a 48-inch blade and an open dripproof motor enclosure. It delivers 19,995 cfm with a 3/4 hp…

SKU 3G-OTH-80185

Brand
Dayton
Item
Supply Fan w/Drive Package: Belt Drive, 48 in Blade, Open Dripproof, 19,995 cfm
Category
Belt-Drive Panel Supply Fans with Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
7AD11
Type
Open Dripproof, 19,995 cfm, 3 ph, 3/4 hp
Blade
48 in
Assembled
Unassembled
Enclosure Design
Open Dripproof Motor
Nameplate Voltage
208-230/460V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Supply Fan w/Drive Package: Belt Drive (MPN 7AD11) is an unassembled belt-drive panel supply fan featuring a 48-inch blade and an open dripproof motor enclosure. It delivers 19,995 cfm with a 3/4 hp, 3-phase motor and a nameplate voltage of 208-230/460V AC.

Frequently Asked Questions

What is the DAYTON 7AD11 supply fan used for?

The DAYTON 7AD11 belt-drive panel supply fan is used for general ventilation and air supply in industrial and commercial facilities. It moves 19,995 cfm of air, making it suitable for warehouses, factories, and large workshops that require reliable, high-volume airflow.

What are the specifications of the DAYTON 7AD11 supply fan?

The DAYTON 7AD11 is a belt-drive panel supply fan with a 48-inch blade and an open dripproof motor enclosure. It delivers 19,995 cfm at 3/4 hp, 3-phase, with a nameplate voltage of 208-230/460V AC. The unit is supplied unassembled.

Where to buy the DAYTON 7AD11 supply fan worldwide?

You can source the DAYTON 7AD11 supply fan through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the DAYTON 7AD11 unassembled supply fan?

Installation of the unassembled DAYTON 7AD11 requires assembling the belt-drive system, mounting the fan panel securely, and connecting the 3-phase motor to the correct voltage (208-230/460V AC). Follow standard industrial fan installation practices and consult a qualified electrician for wiring.
