Dayton Supply Fan w/Drive Package: Belt Drive, 42 in Blade, Totally Enclosed, 20,998 cfm - Belt-Drive Panel Supply Fans with Drive Package
DaytonBelt-Drive Panel Supply Fans with Drive Package

Dayton Supply Fan w/Drive Package: Belt Drive, 42 in Blade, Totally Enclosed, 20,998 cfm

The DAYTON Supply Fan w/Drive Package: Belt Drive (SKU 7CC54) is an unassembled belt-drive panel supply fan with a 42-inch blade and a totally enclosed motor. It delivers 20,998 cfm and operates on 208-230/460V AC…

SKU 3G-OTH-79932

Brand
Dayton
Item
Supply Fan w/Drive Package: Belt Drive, 42 in Blade, Totally Enclosed, 20,998 cfm
Category
Belt-Drive Panel Supply Fans with Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
7CC54
Type
Totally Enclosed, 20,998 cfm, 3 ph
Blade
42 in
Assembled
Unassembled
Enclosure Design
Totally Enclosed Motor
Nameplate Voltage
208-230/460V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Supply Fan w/Drive Package: Belt Drive (SKU 7CC54) is an unassembled belt-drive panel supply fan with a 42-inch blade and a totally enclosed motor. It delivers 20,998 cfm and operates on 208-230/460V AC three-phase power. This product is designed for industrial air-moving applications requiring a belt-drive configuration.

Frequently Asked Questions

What is the DAYTON 7CC54 supply fan used for?

The DAYTON 7CC54 belt-drive panel supply fan is used for industrial air-moving applications requiring a belt-drive configuration. It delivers 20,998 cfm and is suitable for ventilation, exhaust, or supply in factories, warehouses, and commercial facilities where a totally enclosed motor is needed.

What are the specifications of the DAYTON 7CC54 supply fan?

The DAYTON 7CC54 is an unassembled belt-drive panel supply fan with a 42-inch blade and a totally enclosed motor. It delivers 20,998 cfm and operates on 208-230/460V AC three-phase power. The manufacturer part number is 7CC54, and the brand is DAYTON.

Where to buy the DAYTON 7CC54 supply fan worldwide?

You can source the DAYTON 7CC54 supply fan through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing for this DAYTON belt-drive fan.

How to install the DAYTON 7CC54 supply fan?

Installation of the DAYTON 7CC54 unassembled belt-drive fan requires mounting the panel securely, connecting the motor to a 208-230/460V AC three-phase power supply, and assembling the drive package per the manufacturer's instructions. Ensure proper alignment of belts and pulleys, and follow local electrical codes for safe operation.
