Dayton Axial Downblast Roof Exhaust Fan: Belt Drive, Includes Drive Pack, 24 in Blade - Clean Air Belt-Drive Hinged Hood Fans with Drive
DaytonClean Air Belt-Drive Hinged Hood Fans with Drive

Dayton Axial Downblast Roof Exhaust Fan: Belt Drive, Includes Drive Pack, 24 in Blade

The Dayton Axial Downblast Roof Exhaust Fan is a belt-drive clean air fan designed for factory roof mounting. It features an open dripproof motor with 115/208-230V AC, 1 speed, and standard efficiency, delivering…

SKU 3G-OTH-79601

Brand
Dayton
Item
Axial Downblast Roof Exhaust Fan: Belt Drive, Includes Drive Pack, 24 in Blade
Category
Clean Air Belt-Drive Hinged Hood Fans with Drive
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
7CF52
Type
Includes Drive Pack, 5,064 cfm, ODP, 1
Blade
24 in
Assembly
Unassembled
Base Shape
Square
Application
Factories
For Air Type
Clean Air
Drive Package
Includes Drive Package
Motor Enclosure
Open Dripproof
Motor Efficiency
Standard-Efficiency Motors
Number of Speeds
1
Mounting Location
Roof
Nameplate Voltage
115/208-230V AC
High-Efficiency Motor
No
Motor Enclosure Design Broad
Open Motor
Exhaust Airflow @ 0.000 in SP - Range
5,000 to 7,999 cfm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton Axial Downblast Roof Exhaust Fan is a belt-drive clean air fan designed for factory roof mounting. It features an open dripproof motor with 115/208-230V AC, 1 speed, and standard efficiency, delivering 5,064 cfm exhaust airflow. The unassembled unit includes a drive package and has a square base shape.

Frequently Asked Questions

What is the Dayton Axial Downblast Roof Exhaust Fan used for?

This Dayton belt-drive fan is designed for factory roof mounting to exhaust clean air. It delivers 5,064 cfm at 0.000 in SP, making it suitable for general ventilation in industrial facilities where open dripproof motors are acceptable.

What are the specifications of the Dayton 7CF52 exhaust fan?

The Dayton 7CF52 has a 24 in blade, belt drive with included drive pack, open dripproof motor at 115/208-230V AC single speed, and standard efficiency. It is unassembled with a square base, rated for clean air and factory roof mounting.

Where to buy the Dayton 7CF52 roof exhaust fan worldwide?

3G Electric supplies the Dayton 7CF52 axial downblast roof exhaust fan to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this belt-drive unit.

How to install the Dayton belt-drive roof exhaust fan?

Installation requires assembling the unassembled unit per Dayton's manual, mounting on a roof curb with proper sealing, and connecting the 115/208-230V AC supply. Ensure the belt drive is tensioned correctly and the open dripproof motor is protected from weather.
