Dayton Blower: 22 1/8 in Wheel Dia, Belt Drive, Includes Drive Pack, 11,550 cfm - Belt-Drive Blowers with Drive
DaytonBelt-Drive Blowers with Drive

Dayton Blower: 22 1/8 in Wheel Dia, Belt Drive, Includes Drive Pack, 11,550 cfm

The Dayton 7HT04 is a belt-drive blower with a 22 1/8-inch wheel diameter, including a drive pack. It delivers 11,550 cfm and is powered by a 7 1/2 hp open motor rated for 230/460V AC with CCW rotation.

SKU 3G-OTH-76790

Brand
Dayton
Item
Blower: 22 1/8 in Wheel Dia, Belt Drive, Includes Drive Pack, 11,550 cfm
Category
Belt-Drive Blowers with Drive
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
7HT04
Type
Belt Drive, Includes Drive Pack, 11,550 cfm, 7 1/2 hp
AC
230/460V
Rotation
CCW
Nominal Voltage
230/460V AC
Motor Housing Design
Open Motor
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 7HT04 is a belt-drive blower with a 22 1/8-inch wheel diameter, including a drive pack. It delivers 11,550 cfm and is powered by a 7 1/2 hp open motor rated for 230/460V AC with CCW rotation.

Frequently Asked Questions

What is the Dayton 7HT04 blower used for?

The Dayton 7HT04 belt-drive blower is used for industrial ventilation, exhaust, and air movement in factories, warehouses, and commercial buildings. Its 11,550 cfm capacity and 7 1/2 hp motor suit high-volume applications like dust collection, drying, or process cooling.

What are the specifications of the Dayton 7HT04 blower?

The Dayton 7HT04 is a belt-drive blower with a 22 1/8-inch wheel diameter, delivering 11,550 cfm. It includes a drive pack, has a 7 1/2 hp open motor rated for 230/460V AC, and features CCW rotation. The motor housing design is open, and the brand is Dayton.

Where to buy the Dayton 7HT04 blower worldwide?

You can source the Dayton 7HT04 blower through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine Dayton components.

How to select a belt-drive blower like the Dayton 7HT04?

Select a belt-drive blower by matching cfm and static pressure to your system's requirements. For the Dayton 7HT04, verify voltage (230/460V AC), wheel diameter (22 1/8 in), and rotation (CCW). Ensure the drive pack is compatible with your motor and pulley setup for efficient operation.
