Dayton Intake Louver: Flanged, Flush Mount, 53 1/2 in H, 23 1/2 in W, Aluminum - Drainable Adjustable-Blade Louvers
DaytonDrainable Adjustable-Blade Louvers

Dayton Intake Louver: Flanged, Flush Mount, 53 1/2 in H, 23 1/2 in W, Aluminum

The Dayton Intake Louver: Flanged (SKU 805TV3) is a drainable adjustable-blade louver designed for intake applications. This flush-mount unit measures 53 1/2 inches in height and 23 1/2 inches in width, constructed…

SKU 3G-OTH-80302

Brand
Dayton
Item
Intake Louver: Flanged, Flush Mount, 53 1/2 in H, 23 1/2 in W, Aluminum
Category
Drainable Adjustable-Blade Louvers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
805TV3
Type
Flush Mount, 23 1/2 in W, Aluminum
H
53 1/2 in
Flange Wd
1 1/2 in
Maximum Air Velocity
1,300 fpm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton Intake Louver: Flanged (SKU 805TV3) is a drainable adjustable-blade louver designed for intake applications. This flush-mount unit measures 53 1/2 inches in height and 23 1/2 inches in width, constructed from aluminum with a 1 1/2-inch flange width. It supports a maximum air velocity of 1,300 fpm.

Frequently Asked Questions

What is the Dayton 805TV3 intake louver used for?

The Dayton 805TV3 intake louver is a drainable adjustable-blade louver designed for intake applications. It is commonly used in commercial and industrial HVAC systems to allow air entry while blocking rain and debris. Its flush-mount aluminum construction suits exterior walls where weather resistance and airflow control are needed.

What are the specifications of the Dayton 805TV3 louver?

The Dayton 805TV3 louver measures 53 1/2 inches in height and 23 1/2 inches in width, with a 1 1/2-inch flange width. It is made of aluminum and supports a maximum air velocity of 1,300 fpm. The unit is a flush-mount, drainable adjustable-blade type designed for intake applications.

Where to buy the Dayton 805TV3 louver worldwide?

3G Electric supplies the Dayton 805TV3 louver worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time. We source and deliver this product to any international destination.

How to install a Dayton flush-mount intake louver?

Install the Dayton 805TV3 louver by securing the flange to a wall opening using appropriate fasteners. Ensure the unit is level and sealed against moisture. Follow standard louver installation practices: verify structural support, allow for drainage, and check that blades move freely. Consult a professional for wall-penetration sealing.
