Dayton Intake Louver: Flanged, Flush Mount, 17 1/2 in H, 35 1/2 in W, Aluminum - Drainable Adjustable-Blade Louvers
DaytonDrainable Adjustable-Blade Louvers

Dayton Intake Louver: Flanged, Flush Mount, 17 1/2 in H, 35 1/2 in W, Aluminum

The Dayton Intake Louver: Flanged (SKU 805TW3) is a drainable adjustable-blade louver designed for intake applications. This flush-mount unit measures 17 1/2 inches in height and 35 1/2 inches in width, constructed…

SKU 3G-OTH-80150

Brand
Dayton
Item
Intake Louver: Flanged, Flush Mount, 17 1/2 in H, 35 1/2 in W, Aluminum
Category
Drainable Adjustable-Blade Louvers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
805TW3
Type
Flush Mount, 35 1/2 in W, Aluminum
H
17 1/2 in
Flange Wd
1 1/2 in
Maximum Air Velocity
1,300 fpm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton Intake Louver: Flanged (SKU 805TW3) is a drainable adjustable-blade louver designed for intake applications. This flush-mount unit measures 17 1/2 inches in height and 35 1/2 inches in width, constructed from aluminum with a 1 1/2-inch flange width. It has a maximum air velocity rating of 1,300 fpm.

Frequently Asked Questions

What is the Dayton 805TW3 intake louver used for?

The Dayton 805TW3 is a drainable adjustable-blade louver designed for intake applications. It is commonly used in commercial and industrial HVAC systems to allow fresh air entry while preventing water and debris ingress. Its flush-mount, flanged design suits wall openings where a clean exterior appearance is required.

What are the specifications of the Dayton 805TW3 louver?

The Dayton 805TW3 intake louver has a maximum air velocity of 1,300 fpm. It measures 17 1/2 inches in height and 35 1/2 inches in width, with a 1 1/2-inch flange width. The unit is constructed from aluminum and features a drainable adjustable-blade design for intake applications.

Where to buy the Dayton 805TW3 louver worldwide?

3G Electric supplies the Dayton 805TW3 intake louver to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and a quote tailored to your project requirements.

How to install the Dayton 805TW3 flush-mount louver?

Install the Dayton 805TW3 louver by securing the flanged frame to the wall opening with appropriate fasteners, ensuring a weather-tight seal. The drainable blades should be oriented to allow water runoff. Follow standard louver installation practices and consult a professional for structural mounting and duct connections.
