Dayton Banded V-Belt: 3/BX65, 3 Ribs, 68 in Outside Lg, 2 1/4 in Top Wd - BX Section Banded V-Belts
DaytonBX Section Banded V-Belts

Dayton Banded V-Belt: 3/BX65, 3 Ribs, 68 in Outside Lg, 2 1/4 in Top Wd

The DAYTON Banded V-Belt (3/BX65, SKU 816XX9) is a BX Section banded V-belt with 3 ribs, a 2 1/4 in top width, and a 68 in nominal/outside length. 3G Electric sources this OEM part across 14 industrial departments…

SKU 3G-OTH-113502

Brand
Dayton
Item
Banded V-Belt: 3/BX65, 3 Ribs, 68 in Outside Lg, 2 1/4 in Top Wd
Category
BX Section Banded V-Belts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
816XX9
Top Wd
2 1/4 in
Ribs
3
Nominal Lg
68 in
Outside Lg
68 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Banded V-Belt (3/BX65, SKU 816XX9) is a BX Section banded V-belt with 3 ribs, a 2 1/4 in top width, and a 68 in nominal/outside length. 3G Electric sources this OEM part across 14 industrial departments, with specialist depth in power transmission and controls to support your application.

Frequently Asked Questions

What is the DAYTON Banded V-Belt 816XX9 used for?

The DAYTON Banded V-Belt 816XX9 is used in industrial power transmission systems where multiple belts are needed to drive heavy loads. Its banded design prevents belt whip and turnover, making it ideal for HVAC, pumps, compressors, and conveyor applications that require stable, synchronized operation.

What are the specifications of the DAYTON Banded V-Belt 816XX9?

The DAYTON Banded V-Belt 816XX9 is a BX section belt with 3 ribs, a 68-inch outside length, a 2 1/4-inch top width, and a 68-inch nominal length. The manufacturer part number is 816XX9. It is designed for high-torque, heavy-duty industrial drives requiring multiple belt strands.

Where to buy the DAYTON Banded V-Belt 816XX9 worldwide?

You can source the DAYTON Banded V-Belt 816XX9 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide reliable sourcing for this Dayton belt.

How to select the correct DAYTON Banded V-Belt for my application?

To select the correct DAYTON Banded V-Belt, match the belt section (BX), number of ribs (3), and outside length (68 inches) to your drive system's pulley groove dimensions and center distance. Ensure the top width (2 1/4 inches) fits the sheave. Consult Dayton's catalog or a 3G Electric specialist for application-specific guidance.

Used in

Common applications for Dayton
HVAC ventilation — DAYTON centrifugal upblast roof exhaust fans (SKU 7M7U3) for kitchen exhaust systems
Mechanical power transmission — DAYTON HTD timing pulleys (SKU 404GV0) for conveyor belt drives
Process water handling — DAYTON self-priming centrifugal pumps (SKU 2ZXT4) for dewatering or transfer
Roofing and building services — DAYTON fixed ventilated roof curbs (SKU 4HX59) for filtered supply fan installations
Material handling — DAYTON latch assemblies (SKU 2KEN4) for electric chain hoist hook safety
Industrial air movement — DAYTON downblast roof exhaust fans (SKU 3HFL9) for clean air exhaust in manufacturing plants
