DDS Rotary Shaft Seal: 1 Lip w/Spring, SB, Nitrile, 9 mm ID, 17 mm OD, 4.5 mm Wd - Single-Lip Oil Seals with Metal Cases for Smooth Bores
DDSSingle-Lip Oil Seals with Metal Cases for Smooth Bores

DDS Rotary Shaft Seal: 1 Lip w/Spring, SB, Nitrile, 9 mm ID, 17 mm OD, 4.5 mm Wd

The DDS Rotary Shaft Seal is a single-lip oil seal with a metal case, designed for smooth bores. This metric SB-design seal features a nitrile lip with a spring, a 9 mm inner diameter, a 17 mm outer diameter, and a…

SKU 3G-OTH-123672

Brand
DDS
Item
Rotary Shaft Seal: 1 Lip w/Spring, SB, Nitrile, 9 mm ID, 17 mm OD, 4.5 mm Wd
Category
Single-Lip Oil Seals with Metal Cases for Smooth Bores
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

DDS
Manufacturer Part Number
09174.5SB
Type
SB, Nitrile
OD
17 mm
Wd
4.5 mm
ID
9 mm
Seal Design
SB
Max Pressure
7 psi
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

DDS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DDS Rotary Shaft Seal is a single-lip oil seal with a metal case, designed for smooth bores. This metric SB-design seal features a nitrile lip with a spring, a 9 mm inner diameter, a 17 mm outer diameter, and a 4.5 mm width, with a maximum pressure rating of 7 psi (MPN 09174.5SB).

Frequently Asked Questions

What is the DDS Rotary Shaft Seal 09174.5SB used for?

The DDS Rotary Shaft Seal 09174.5SB is a single-lip oil seal with a metal case, designed to retain lubricants and exclude contaminants in rotating shaft applications. It is commonly used in pumps, gearboxes, and motors where a smooth bore housing and metric shaft dimensions (9 mm ID, 17 mm OD) are present.

What are the specifications of the DDS Rotary Shaft Seal 09174.5SB?

The DDS Rotary Shaft Seal 09174.5SB has a 9 mm inner diameter, 17 mm outer diameter, and 4.5 mm width. It features an SB seal design with a nitrile lip and spring, rated for a maximum pressure of 7 psi. The system of measurement is metric, and the manufacturer part number is 09174.5SB.

Where to buy the DDS Rotary Shaft Seal 09174.5SB worldwide?

You can source the DDS Rotary Shaft Seal 09174.5SB through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide this seal as part of our extensive sourcing network.

How to install the DDS Rotary Shaft Seal 09174.5SB?

To install the DDS Rotary Shaft Seal 09174.5SB, ensure the housing bore is smooth and clean. Use a seal driver or press to apply even pressure on the metal case outer diameter, seating the seal squarely. Avoid damaging the nitrile lip. Lubricate the lip lightly before installation to prevent dry start.
