DDS Rotary Shaft Seal: 1 Lip w/Spring, SF, Nitrile, 205 mm ID, 230 mm OD - Single-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores
DDSSingle-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores

DDS Rotary Shaft Seal: 1 Lip w/Spring, SF, Nitrile, 205 mm ID, 230 mm OD

The DDS Rotary Shaft Seal is a single-lip oil seal with a rubber-enclosed case designed for rough bores. This metric seal, model SF (MPN 20523016SF), features a nitrile construction with a 205 mm inner diameter, 230…

SKU 3G-OTH-125445

Brand
DDS
Item
Rotary Shaft Seal: 1 Lip w/Spring, SF, Nitrile, 205 mm ID, 230 mm OD
Category
Single-Lip Oil Seals with Rubber-Enclosed Cases for Rough Bores
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

DDS
Manufacturer Part Number
20523016SF
Type
SF, Nitrile
OD
230 mm
Wd
16 mm
ID
205 mm
Seal Design
SF
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

DDS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DDS Rotary Shaft Seal is a single-lip oil seal with a rubber-enclosed case designed for rough bores. This metric seal, model SF (MPN 20523016SF), features a nitrile construction with a 205 mm inner diameter, 230 mm outer diameter, and 16 mm width, and includes a spring for lip tension.

Frequently Asked Questions

What is the DDS Rotary Shaft Seal 20523016SF used for?

The DDS Rotary Shaft Seal 20523016SF is a single-lip oil seal with a rubber-enclosed case designed for rough bores. It seals rotating shafts in industrial equipment such as gearboxes, pumps, and motors, preventing lubricant leakage and contaminant ingress. Its nitrile construction and spring-loaded lip ensure reliable performance in demanding applications.

What are the specifications of the DDS Rotary Shaft Seal 20523016SF?

The DDS Rotary Shaft Seal 20523016SF is a metric seal with a 205 mm inner diameter, 230 mm outer diameter, and 16 mm width. It features a single lip with a spring, nitrile material, and an SF seal design with a rubber-enclosed case for rough bores. The manufacturer part number is 20523016SF.

Where to buy the DDS Rotary Shaft Seal 20523016SF worldwide?

You can source the DDS Rotary Shaft Seal 20523016SF through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide reliable sourcing for this DDS seal.

How to install the DDS Rotary Shaft Seal 20523016SF?

To install the DDS Rotary Shaft Seal 20523016SF, ensure the housing bore is clean and free of burrs. Press the seal evenly into the bore using a suitable driver, applying force on the outer case only. Lubricate the lip lightly before installation. Avoid damaging the sealing lip or spring during assembly.
