DIODE LED Driver: 96 W Power Output, 100 to 277V AC, 24V DC, 9 in Lg, Wet Location Rated - Color-Changing Decoders with Built-in Power Supply
DIODE LEDColor-Changing Decoders with Built-in Power Supply

DIODE LED Driver: 96 W Power Output, 100 to 277V AC, 24V DC, 9 in Lg, Wet Location Rated

The DIODE LED 820EG3 is a color-changing decoder with a built-in power supply, delivering 96 W of power output. It operates on an input voltage of 100 to 277V AC and provides a 24V DC output. The unit includes a NEMA…

SKU 3G-OTH-392116

Brand
DIODE LED
Item
Driver: 96 W Power Output, 100 to 277V AC, 24V DC, 9 in Lg, Wet Location Rated
Category
Color-Changing Decoders with Built-in Power Supply
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

DIODE LED
Manufacturer Part Number
DI-DMX-DCO-24V96W-277-LPS3R
Type
Wet Location Rated
Lg
9 in
AC
100 to 277V
DC
24V
Ht
1 5/16 in
Power Output
96 W
Input Voltage
100 to 277V AC
Output Voltage
24V DC
Junction Box Included
NEMA 3 Junction Box
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

DIODE LED Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DIODE LED 820EG3 is a color-changing decoder with a built-in power supply, delivering 96 W of power output. It operates on an input voltage of 100 to 277V AC and provides a 24V DC output. The unit includes a NEMA 3 junction box and is rated for wet locations.

Frequently Asked Questions

What is the DIODE LED 820EG3 color-changing decoder used for?

The DIODE LED 820EG3 is a color-changing decoder with a built-in power supply, designed for architectural and landscape lighting systems. It controls RGB or RGBW LED tape lights in wet locations, delivering 96 W at 24V DC from a 100 to 277V AC input.

What are the specifications of the DIODE LED 820EG3?

The DIODE LED 820EG3 delivers 96 W power output, operates on 100 to 277V AC input, and provides 24V DC output. It includes a NEMA 3 junction box and is wet-location rated. The unit measures 9 in long by 1 5/16 in high.

Where to buy the DIODE LED 820EG3 worldwide?

3G Electric supplies the DIODE LED 820EG3 worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the DIODE LED 820EG3 decoder?

Mount the NEMA 3 junction box in a wet location, connect the 100 to 277V AC input to the built-in power supply, and wire the 24V DC output to your LED tape. Follow DIODE LED's wiring diagram for DMX control signals. Ensure proper grounding per local codes.

Used in

Common applications for DIODE LED
Architectural cove lighting — DIODE LED TE series 32.8 ft spools for indirect illumination in ceiling coves
Under-cabinet task lighting — DIODE LED MSE series 16.4 ft spools for work surface illumination in kitchens or labs
Retail display accent lighting — DIODE LED 3D series spools with side-bend flexibility for shelf edge lighting
Signage channel letters — DIODE LED M3D series low-profile spools for backlighting acrylic letters
Industrial machine vision — DIODE LED 4000K spools for consistent white light in inspection stations
Linear pathway lighting — DIODE LED top-bend spools mounted in aluminum channels for walkway illumination
