DIXON Butterfly Valve: 1 in Pipe Size, Clamp, 140 psi Max. Pressure (CWP), 316L Stainless Steel - 3-A Certified Stainless Steel Butterfly Valves
DIXON3-A Certified Stainless Steel Butterfly Valves

DIXON Butterfly Valve: 1 in Pipe Size, Clamp, 140 psi Max. Pressure (CWP), 316L Stainless Steel

The DIXON Butterfly Valve is a 3-A Certified stainless steel butterfly valve with a 1-inch pipe size, featuring a 316L SS body and disc, a lever handle, and 13 stop positions. It has a maximum pressure rating of 140…

SKU 3G-OTH-453420

Brand
DIXON
Item
Butterfly Valve: 1 in Pipe Size, Clamp, 140 psi Max. Pressure
Category
3-A Certified Stainless Steel Butterfly Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

DIXON
Manufacturer Part Number
B5107E100CC-C
Type
Clamp, 13
Handle Type
Lever
Body Material
316L SS
Disc Material
316L SS
Stop Positions
13
Stainless Steel
316L
Max. Pressure (CWP)
140 psi
Average Surface Roughness (Ra)
≤ 32 micron
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

DIXON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DIXON Butterfly Valve is a 3-A Certified stainless steel butterfly valve with a 1-inch pipe size, featuring a 316L SS body and disc, a lever handle, and 13 stop positions. It has a maximum pressure rating of 140 psi (CWP) and an average surface roughness (Ra) of ≤ 32 micron.

Frequently Asked Questions

What is the DIXON Butterfly Valve used for?

The DIXON Butterfly Valve is used for on-off flow control in sanitary processing lines, such as food, dairy, beverage, and pharmaceutical applications. Its 3-A Certification and 316L stainless steel construction with ≤ 32 micron surface roughness ensure compliance with hygienic standards.

What are the specifications of the DIXON Butterfly Valve B5107E100CC-C?

This DIXON Butterfly Valve has a 1-inch pipe size, clamp connection, 316L SS body and disc, lever handle, 13 stop positions, and a maximum pressure rating of 140 psi (CWP). The average surface roughness (Ra) is ≤ 32 micron, meeting 3-A sanitary requirements.

Where to buy the DIXON Butterfly Valve worldwide?

3G Electric supplies the DIXON Butterfly Valve B5107E100CC-C to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this 3-A certified valve.

How to install a DIXON 3-A Butterfly Valve?

Install the DIXON Butterfly Valve between two sanitary clamp ferrules using a gasket and clamp. Ensure the valve disc is fully open during installation to avoid damage. Tighten the clamp evenly to the manufacturer's torque specification. Verify the lever handle operates smoothly through all 13 stop positions.

Used in

Common applications for DIXON
Food and beverage processing — DIXON 3-A Certified butterfly valves (e.g., MPN B5107E400CC-C) for sanitary flow control in dairy lines.
Pharmaceutical manufacturing — DIXON 316L stainless steel butterfly valves (e.g., MPN B5107V200BB-B) for sterile fluid handling.
Water treatment plants — DIXON butterfly valves with solder connections (e.g., MPN B5107S250BB-B) for isolation and throttling in piping systems.
Chemical processing — DIXON butterfly valves with EPDM seats (e.g., MPN B5107E400CC-C) for handling mild chemicals and hot water.
Brewery and beverage production — DIXON clamp-end butterfly valves (e.g., MPN B5107S100CC-B) for quick disassembly and cleaning in process lines.
Dairy processing — DIXON 3-A Certified butterfly valves (e.g., MPN B5107E075BB-B) for CIP-compatible flow control in milk and yogurt lines.
