DIXON Butterfly Valve: 4 in Pipe Size, Clamp, 85 psi Max. Pressure (CWP), 304 Stainless Steel - 3-A Certified Stainless Steel Butterfly Valves
DIXON3-A Certified Stainless Steel Butterfly Valves

DIXON Butterfly Valve: 4 in Pipe Size, Clamp, 85 psi Max. Pressure (CWP), 304 Stainless Steel

The DIXON Butterfly Valve is a 3-A Certified stainless steel butterfly valve with a 4-inch pipe size, featuring a 304 SS body and disc, a lever handle, and 24 stop positions. It has a maximum pressure rating of 85…

SKU 3G-OTH-453310

Brand
DIXON
Item
Butterfly Valve: 4 in Pipe Size, Clamp, 85 psi Max. Pressure
Category
3-A Certified Stainless Steel Butterfly Valves
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

DIXON
Manufacturer Part Number
L5107E400CC-P
Type
Clamp, EPDM
Handle Type
Lever
Body Material
304 SS
Disc Material
304 SS
Stop Positions
24
Stainless Steel
304
Max. Pressure (CWP)
85 psi
Average Surface Roughness (Ra)
≤ 32 micron
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

DIXON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DIXON Butterfly Valve is a 3-A Certified stainless steel butterfly valve with a 4-inch pipe size, featuring a 304 SS body and disc, a lever handle, and 24 stop positions. It has a maximum pressure rating of 85 psi (CWP) and an average surface roughness (Ra) of ≤ 32 micron, with an EPDM seal.

Frequently Asked Questions

What is the DIXON Butterfly Valve used for?

The DIXON Butterfly Valve is used in food, dairy, beverage, and pharmaceutical processing for on-off flow control of liquids and gases. Its 3-A certification and 304 SS construction with ≤ 32 micron Ra surface finish meet sanitary standards, making it suitable for clean-in-place (CIP) systems.

What are the specifications of the DIXON Butterfly Valve?

This DIXON valve has a 4-inch pipe size, clamp connection, 304 SS body and disc, EPDM seal, lever handle with 24 stop positions, and a maximum pressure rating of 85 psi (CWP). The average surface roughness (Ra) is ≤ 32 micron. The manufacturer part number is L5107E400CC-P.

Where to buy the DIXON Butterfly Valve worldwide?

3G Electric supplies the DIXON Butterfly Valve worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this 3-A certified sanitary valve.

How to install the DIXON Butterfly Valve?

Install the DIXON Butterfly Valve between two clamp ferrules using a compatible gasket and clamp. Ensure the EPDM seal is properly seated and the lever handle aligns with the 24 stop positions. Tighten the clamp evenly to avoid leakage. Follow standard sanitary piping practices for 304 SS components.

Used in

Common applications for DIXON
Food and beverage processing — DIXON 3-A Certified butterfly valves (e.g., MPN B5107E400CC-C) for sanitary flow control in dairy lines.
Pharmaceutical manufacturing — DIXON 316L stainless steel butterfly valves (e.g., MPN B5107V200BB-B) for sterile fluid handling.
Water treatment plants — DIXON butterfly valves with solder connections (e.g., MPN B5107S250BB-B) for isolation and throttling in piping systems.
Chemical processing — DIXON butterfly valves with EPDM seats (e.g., MPN B5107E400CC-C) for handling mild chemicals and hot water.
Brewery and beverage production — DIXON clamp-end butterfly valves (e.g., MPN B5107S100CC-B) for quick disassembly and cleaning in process lines.
Dairy processing — DIXON 3-A Certified butterfly valves (e.g., MPN B5107E075BB-B) for CIP-compatible flow control in milk and yogurt lines.
