DIXON VALVE & COUPLING Cam and Groove Coupling: 1 1/2 in Coupling Size, 1 in Hose Fitting Size - Type B Aluminum Cam & Groove Fittings
DIXON VALVE & COUPLINGType B Aluminum Cam & Groove Fittings

DIXON VALVE & COUPLING Cam and Groove Coupling: 1 1/2 in Coupling Size, 1 in Hose Fitting Size

The DIXON VALVE & COUPLING Type B Aluminum Cam & Groove Fitting (SKU 55MF88, MPN 1510-B-AL) is a 1 1/2 in coupling size fitting with a 1 in -11-1/2 MNPT thread and a nitrile gasket. This aluminum cam and groove…

SKU 3G-OTH-451449

Brand
DIXON VALVE & COUPLING
Item
Cam and Groove Coupling: 1 1/2 in Coupling Size, 1 in Hose Fitting Size
Category
Type B Aluminum Cam & Groove Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

DIXON VALVE & COUPLING
Manufacturer Part Number
1510-B-AL
Type
1 in -11-1/2 Thread Size
Thread Size
1 in -11-1/2
Fitting Type
MNPT
Gasket Material
Nitrile
Hose Fitting Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

DIXON VALVE & COUPLING Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DIXON VALVE & COUPLING Type B Aluminum Cam & Groove Fitting (SKU 55MF88, MPN 1510-B-AL) is a 1 1/2 in coupling size fitting with a 1 in -11-1/2 MNPT thread and a nitrile gasket. This aluminum cam and groove coupling is designed for quick-connect hose and pipe applications.

Frequently Asked Questions

What is a DIXON VALVE & COUPLING Type B aluminum cam and groove coupling used for?

This DIXON VALVE & COUPLING Type B aluminum cam and groove coupling is used for quick-connect hose and pipe applications in industrial fluid transfer. It provides a secure, leak-resistant connection for transferring liquids, powders, or gases in industries like chemical processing, agriculture, and petroleum.

What are the specifications of the DIXON 1510-B-AL cam and groove coupling?

The DIXON 1510-B-AL is a Type B aluminum cam and groove coupling with a 1 1/2 in coupling size, 1 in hose fitting size, and 1 in -11-1/2 MNPT thread. It includes a nitrile gasket for sealing. The fitting is made of aluminum for corrosion resistance and lightweight handling.

Where to buy DIXON cam and groove couplings worldwide?

3G Electric supplies DIXON cam and groove couplings worldwide. As a global industrial solutions provider, we handle logistics, customs clearance, and delivery to your site. Contact us to source the DIXON 1510-B-AL or other cam and groove fittings for your application.

How to install a DIXON cam and groove coupling?

To install a DIXON cam and groove coupling, ensure the gasket is properly seated in the groove. Align the coupling ends and close the cam arms over the mating adapter. Verify the arms are fully locked. For threaded connections, apply thread sealant to the MNPT fitting and tighten to recommended torque.

Used in

Common applications for DIXON VALVE & COUPLING
Chemical transfer — Dixon Type D forged brass cam and groove couplings for loading and unloading hoses in chemical processing plants.
Compressed air systems — Dixon Bowes Safety-Lock steel quick-connect plugs (e.g., N4M4-LS) for pneumatic tool connections in manufacturing facilities.
Marine fuel handling — Dixon Type C 316 stainless steel cam and groove couplings for fuel transfer hoses on vessels and docks.
Bulk material handling — Dixon Type AL stainless steel adapters (e.g., 150-AL-SS) for connecting hoses to flanged pipes in grain or powder transfer systems.
Water supply lines — Dixon Type F forged brass adapters for temporary water connections in construction or agricultural irrigation.
Dust protection — Dixon Type DC stainless steel dust caps for sealing unused cam and groove couplings in outdoor or washdown environments.
