DIXON VALVE & COUPLING Dust Cap: 5 in Coupling Size, 75 psi Max. Working Pressure @ 70 F, 3 27/32 in Overall Lg

This dust cap seals the end of a cam-and-groove coupling when not in use, preventing dirt, debris, and moisture from entering the line. It is commonly used in industrial fluid-transfer applications such as chemical, petroleum, and bulk-handling systems where a clean, leak-free connection is required.

The DIXON VALVE & COUPLING G500-DC-BR is a 5-inch coupling-size forged brass dust cap with a nitrile gasket. It has a maximum working pressure of 75 psi at 70°F and an overall length of 3 27/32 inches. The nitrile gasket provides good resistance to oils and fuels.

3G Electric supplies DIXON VALVE & COUPLING dust caps worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on the G500-DC-BR or other cam-and-groove dust caps.

To install, ensure the coupling adapter is clean and free of debris. Align the dust cap's cam arms with the adapter's grooves, then press down and lock the arms into place. The nitrile gasket creates a seal. For removal, lift both cam arms simultaneously and pull the cap off. No tools are required.
