Dwyer Indicating Differential Transmitter: Dial, 0 in wc to 1 in wc, Screw Terminals - Differential Pressure Transmitters with Dial Display
DwyerDifferential Pressure Transmitters with Dial Display

Dwyer Indicating Differential Transmitter: Dial, 0 in wc to 1 in wc, Screw Terminals

The DWYER Indicating Differential Transmitter: Dial (MPN 605-1) is a differential pressure transmitter with a dial display from the Magnehelic 605 series. It provides a 4 to 20mA DC output with ±2% electrical…

SKU 3G-OTH-174084

Brand
Dwyer
Item
Indicating Differential Transmitter: Dial, 0 in wc to 1 in wc, Screw Terminals
Category
Differential Pressure Transmitters with Dial Display
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dwyer
Manufacturer Part Number
605-1
Series
Magnehelic 605
Type
0 in wc to 1 in wc, Screw Terminals
Dia
5.5 in
Accuracy
±2% (Electrical)
Display Type
Dial
Output Power
4 to 20mA DC
Indicator Type
Analog / Dial
Process Connection Type
NPT
Process Connection Gender
Female
Includes NIST-Traceable Calibration Certificate
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dwyer Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DWYER Indicating Differential Transmitter: Dial (MPN 605-1) is a differential pressure transmitter with a dial display from the Magnehelic 605 series. It provides a 4 to 20mA DC output with ±2% electrical accuracy and features a female NPT process connection. The unit has a 0 in wc to 1 in wc range and includes screw terminals.

Frequently Asked Questions

What is the DWYER Magnehelic 605-1 differential pressure transmitter used for?

The DWYER Magnehelic 605-1 is used to measure and transmit differential pressure in HVAC, cleanroom, and industrial process applications. It provides a 4 to 20mA DC output with a dial display, making it suitable for monitoring filter pressure drop, airflow, and liquid levels in low-pressure systems.

What are the specifications of the DWYER 605-1 differential pressure transmitter?

The DWYER 605-1 has a 0 in wc to 1 in wc range, ±2% electrical accuracy, and a 4 to 20mA DC output. It features a dial display, female NPT process connection, and screw terminals. This Magnehelic 605 series unit does not include a NIST-traceable calibration certificate.

Where to buy the DWYER 605-1 differential pressure transmitter worldwide?

You can source the DWYER 605-1 differential pressure transmitter from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this Magnehelic 605 series unit.

How to install the DWYER 605-1 differential pressure transmitter?

Mount the DWYER 605-1 in a vertical position using the female NPT connections. Connect the 4 to 20mA DC output via screw terminals, ensuring proper polarity. Apply pressure within the 0 in wc to 1 in wc range. For best accuracy, avoid vibration and follow standard wiring practices for Dwyer transmitters.

Used in

Common applications for Dwyer
Combustion air-filter monitoring — Magnehelic Series 2000 on burner air-intake filter banks
Clean-room and pharmaceutical pressurisation — Magnehelic / Capsuhelic differential-pressure gauges
HVAC fan-discharge static pressure — Mark II inclined-vertical manometers on AHU test points
Filter-blockage alarms — Photohelic Series 3000 combined gauge/switch on air-handling units
BMS-integrated pressure monitoring — Digihelic DH3 with 4–20 mA output for building management
