E-Z LOK Self Locking Thread Insert: Heavy Wall, 1/4"-28 Int Thrd Sz, 7/16"-14 Ext Thrd Sz - Heavy Wall Self-Locking Inserts
E-Z LOKHeavy Wall Self-Locking Inserts

E-Z LOK Self Locking Thread Insert: Heavy Wall, 1/4"-28 Int Thrd Sz, 7/16"-14 Ext Thrd Sz

The E-Z LOK Self Locking Thread Insert is a heavy-wall, inch-system insert with a 1/4"-28 UNF internal thread and a 7/16"-14 UNC external thread, supplied as a 5-pack (MPN 303-428-PK5). It features a 2B internal…

SKU 3G-OTH-534110

Brand
E-Z LOK
Item
Self Locking Thread Insert: Heavy Wall, 1/4"-28 Int Thrd Sz, 7/16"-14 Ext Thrd Sz
Category
Heavy Wall Self-Locking Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

E-Z LOK
Manufacturer Part Number
303-428-PK5
Type
5 PK
Wall Type
Heavy Wall
Ext Thrd Sz
7/16"-14
Int Thrd Sz
1/4"-28
Thread Type
UNF Internal/UNC External
Compatible Tap Size
7/16"-14
External Thread Fit
2A
Internal Thread Fit
2B
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

E-Z LOK Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The E-Z LOK Self Locking Thread Insert is a heavy-wall, inch-system insert with a 1/4"-28 UNF internal thread and a 7/16"-14 UNC external thread, supplied as a 5-pack (MPN 303-428-PK5). It features a 2B internal thread fit and a 2A external thread fit, compatible with a 7/16"-14 tap. 3G Electric sources this genuine OEM component across 14 industrial departments, with specialist expertise in fastening and assembly solutions.

Frequently Asked Questions

What is E-Z LOK Self Locking Thread Insert used for?

E-Z LOK Self Locking Thread Inserts repair or reinforce tapped holes in metal, plastic, or wood. The heavy-wall design provides strong, wear-resistant threads for demanding industrial applications. 3G Electric supplies this genuine OEM component across 14 industrial departments, with specialist expertise in fastening and assembly solutions.

What are the specifications of E-Z LOK 303-428-PK5?

This heavy-wall insert has a 1/4"-28 UNF internal thread and a 7/16"-14 UNC external thread, with 2B internal and 2A external thread fits. It is compatible with a 7/16"-14 tap, uses inch measurement, and comes as a 5-pack (MPN 303-428-PK5).

Where to buy E-Z LOK thread inserts in worldwide?

3G Electric supplies E-Z LOK thread inserts worldwide, handling full logistics and customs clearance. As a global industrial solutions provider, we source genuine OEM components across 14 departments. Contact us for pricing and delivery to your location.

How to install E-Z LOK self locking thread inserts?

Installation requires tapping a hole to the specified external thread size (7/16"-14), then driving the insert into the tapped hole using a standard installation tool. The self-locking feature engages upon insertion. Always follow the manufacturer's instructions for torque and depth.
