EATON Pilot Light: 30 mm Panel Mounting Size, Amber, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Pilot Light: 30 mm Panel Mounting Size, Amber, LED

The EATON HT8HBAL1 is an LED pilot light from the HT800 series, featuring a 30 mm panel mounting size and an amber LED with a maximum supply voltage rating of 120 V AC. This unit does not include a push-to-test function.

SKU 3G-OTH-33252

Brand
EATON
Item
Pilot Light: 30 mm Panel Mounting Size, Amber, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
HT8HBAL1
Series
HT800
Type
Amber, LED
Includes Push-To-Test
No Push-To-Test Included
AC Max Volt Rating (Supply)
120 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON HT8HBAL1 is an LED pilot light from the HT800 series, featuring a 30 mm panel mounting size and an amber LED with a maximum supply voltage rating of 120 V AC. This unit does not include a push-to-test function.
