EATON Pilot Light: 30 mm Panel Mounting Size, Green, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Pilot Light: 30 mm Panel Mounting Size, Green, LED

The EATON HT8GTGL1 is a green LED pilot light from the HT800 series, featuring a 30 mm panel mounting size and a maximum supply voltage rating of 120 V AC. This unit includes a push-to-test function for verifying…

SKU 3G-OTH-36127

Brand
EATON
Item
Pilot Light: 30 mm Panel Mounting Size, Green, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
HT8GTGL1
Series
HT800
Type
Green, LED
Includes Push-To-Test
Push-To-Test Included
AC Max Volt Rating (Supply)
120 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON HT8GTGL1 is a green LED pilot light from the HT800 series, featuring a 30 mm panel mounting size and a maximum supply voltage rating of 120 V AC. This unit includes a push-to-test function for verifying operation.

Frequently Asked Questions

What is the EATON HT8GTGL1 pilot light used for?

The EATON HT8GTGL1 is a green LED pilot light used as a visual status indicator on industrial control panels, machinery, and automation systems. Its push-to-test function allows operators to verify the light is working without disassembling the panel, making it suitable for safety-critical applications in manufacturing and process industries.

What are the specifications of the EATON HT8GTGL1 pilot light?

The EATON HT8GTGL1 is a green LED pilot light from the HT800 series with a 30 mm panel mounting size. It has a maximum supply voltage rating of 120 V AC and includes a push-to-test feature. The manufacturer part number is HT8GTGL1, and it is designed for reliable status indication in industrial environments.

Where to buy the EATON HT8GTGL1 pilot light worldwide?

3G Electric supplies the EATON HT8GTGL1 pilot light worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this EATON HT800 series component to any country.

How to install the EATON HT8GTGL1 pilot light?

To install the EATON HT8GTGL1, mount it in a 30 mm panel cutout and secure it with the provided locking ring. Connect the supply voltage up to 120 V AC to the terminals, ensuring proper polarity for the LED. Use the push-to-test button to confirm operation before finalizing the panel assembly. Follow standard industrial wiring practices.
