EATON Pilot Light: 30 mm Panel Mounting Size, White, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Pilot Light: 30 mm Panel Mounting Size, White, LED

The EATON HT8GTWL1 is a 30 mm panel-mounting-size LED pilot light from the HT800 series. It features a white LED with a maximum supply voltage rating of 120 V AC and includes a push-to-test function for verifying…

SKU 3G-OTH-36427

Brand
EATON
Item
Pilot Light: 30 mm Panel Mounting Size, White, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
HT8GTWL1
Series
HT800
Type
White, LED
Includes Push-To-Test
Push-To-Test Included
AC Max Volt Rating (Supply)
120 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON HT8GTWL1 is a 30 mm panel-mounting-size LED pilot light from the HT800 series. It features a white LED with a maximum supply voltage rating of 120 V AC and includes a push-to-test function for verifying operation.

Frequently Asked Questions

What is the EATON HT8GTWL1 pilot light used for?

The EATON HT8GTWL1 is a 30 mm panel-mounting LED pilot light used in industrial control panels to indicate machine status or power-on condition. Its white LED and push-to-test function help operators verify operation at a glance, common in manufacturing, HVAC, and process control applications.

What are the specifications of the EATON HT8GTWL1 pilot light?

The EATON HT8GTWL1 is a white LED pilot light from the HT800 series with a 30 mm panel mounting size. It has a maximum supply voltage rating of 120 V AC and includes a push-to-test feature. The manufacturer part number is HT8GTWL1.

Where to buy the EATON HT8GTWL1 pilot light worldwide?

3G Electric supplies the EATON HT8GTWL1 pilot light worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this HT800 series LED pilot light.

How to install the EATON HT8GTWL1 pilot light?

To install the EATON HT8GTWL1, mount it in a 30 mm panel cutout and connect the supply wires to a 120 V AC source. Use the push-to-test button to verify the LED illuminates. Follow standard industrial control panel wiring practices and ensure power is off before installation.
