EATON Illuminated Push Button: Illuminated, Extended Profile, Metallic, 30 mm
The EATON Illuminated Extended-Length Push Button (SKU 13Z658, MPN HT8GBYABF7) is a momentary-action, metallic push button from the HT800 series. It features an illuminated, extended profile in a 30 mm size with…
SKU 3G-OTH-32617
Need installation or engineering help?
Ask a question
Product Description
The EATON Illuminated Extended-Length Push Button (SKU 13Z658, MPN HT8GBYABF7) is a momentary-action, metallic push button from the HT800 series. It features an illuminated, extended profile in a 30 mm size with 1NO/1NC contact configuration.
Frequently Asked Questions
What is the EATON illuminated push button used for?
The EATON illuminated push button (MPN HT8GBYABF7) is used for momentary control in industrial machinery, panel building, and process automation. Its illuminated extended profile provides clear visual status indication in low-light environments. The metallic 30 mm construction suits heavy-duty applications requiring durability and reliable switching with 1NO/1NC contacts.
What are the specifications of the EATON HT8GBYABF7 push button?
The EATON HT8GBYABF7 is a momentary-action, illuminated push button from the HT800 series. It has a metallic extended profile, 30 mm mounting size, and 1NO/1NC contact configuration. The push button material is metallic, and the part number is HT8GBYABF7 (SKU 13Z658). It is designed for industrial control applications.
Where to buy the EATON HT8GBYABF7 push button worldwide?
You can source the EATON HT8GBYABF7 illuminated push button worldwide through 3G Electric. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we supply genuine EATON HT800 series components.
How to install the EATON illuminated push button?
Install the EATON HT8GBYABF7 by mounting it in a 30 mm panel cutout and securing with the provided nut. Wire the 1NO/1NC contacts according to your control circuit, ensuring proper voltage for the illumination. Follow standard industrial push button installation practices and verify operation before use. Consult the HT800 series manual for torque and wiring details.
Used in
Common applications for EATONEATON Products
3G Electric supplies EATON illuminated extended-length push buttons. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
