EATON Supplementary Protector: 13 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ - B-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
EATONB-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors

EATON Supplementary Protector: 13 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ

The EATON FAZ-B13/1-SP is a B-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated at 13 A. It features a maximum AIR rating of 15kA at 240/415V AC, AC voltage rating of 277/480V AC, and DC voltage…

SKU 3G-OTH-20863

Brand
EATON
Item
Supplementary Protector: 13 A Amps, 48V DC, 15kA at 240/415V AC, Lug, FAZ
Category
B-Curve, 1-Pole UL1077 DIN Rail-Mount Supplementary Protectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-B13/1-SP
Series
FAZ
Type
15kA at 240/415V AC, Lug, FAZ, B
AC
277/480V
DC
48V
Curve Type
B
Max. AIR Rating
15kA at 240/415V AC
AC Voltage Rating
277/480V AC
DC Voltage Rating
48V DC
Terminal Connection
Lug
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-B13/1-SP is a B-curve, 1-pole UL1077 DIN rail-mount supplementary protector rated at 13 A. It features a maximum AIR rating of 15kA at 240/415V AC, AC voltage rating of 277/480V AC, and DC voltage rating of 48V DC, with lug terminal connections.
