EATON Miniature Circuit Breaker: 7 A Amps, 48/96V DC, 10kA at 277/480V AC, Screw Clamp - C-Curve, 3-Pole UL489 DIN Rail-Mount Miniature Circuit Breakers
EATONC-Curve, 3-Pole UL489 DIN Rail-Mount Miniature Circuit Breakers

EATON Miniature Circuit Breaker: 7 A Amps, 48/96V DC, 10kA at 277/480V AC, Screw Clamp

The EATON FAZ-C7/3-NA is a 7 A, C-curve, 3-pole UL489 DIN rail-mount miniature circuit breaker. It features a maximum AIR rating of 10kA at 277/480V AC and a DC voltage rating of 48/96V DC, with screw clamp terminals.

SKU 3G-OTH-20078

Brand
EATON
Item
Miniature Circuit Breaker: 7 A Amps, 48/96V DC, 10kA at 277/480V AC, Screw Clamp
Category
C-Curve, 3-Pole UL489 DIN Rail-Mount Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
FAZ-C7/3-NA
Type
10kA at 277/480V AC, Screw Clamp, C
DC
48/96V
Max. AIR Rating
10kA at 277/480V AC
DC Voltage Rating
48/96V DC
Terminal Connection
Screw Clamp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON FAZ-C7/3-NA is a 7 A, C-curve, 3-pole UL489 DIN rail-mount miniature circuit breaker. It features a maximum AIR rating of 10kA at 277/480V AC and a DC voltage rating of 48/96V DC, with screw clamp terminals.

Frequently Asked Questions

What is the EATON FAZ-C7/3-NA miniature circuit breaker used for?

The EATON FAZ-C7/3-NA is a 7 A, C-curve, 3-pole UL489 miniature circuit breaker used for overcurrent protection in industrial control panels, HVAC equipment, and machinery. Its 48/96V DC rating suits DC control circuits, while the 10kA at 277/480V AC rating handles branch-circuit protection in commercial and light industrial installations.

What are the specifications of the EATON FAZ-C7/3-NA?

The EATON FAZ-C7/3-NA is a 7 A, C-curve, 3-pole UL489 DIN rail-mount miniature circuit breaker. It has a maximum AIR rating of 10kA at 277/480V AC, a DC voltage rating of 48/96V DC, and screw clamp terminals. The manufacturer part number is FAZ-C7/3-NA.

Where to buy the EATON FAZ-C7/3-NA worldwide?

3G Electric supplies the EATON FAZ-C7/3-NA miniature circuit breaker to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this UL489 DIN rail-mount breaker.

How to select the right EATON miniature circuit breaker for a DC control circuit?

For DC control circuits, match the breaker's DC voltage rating to your system voltage—the EATON FAZ-C7/3-NA is rated 48/96V DC. Choose the C-curve for moderate inrush loads like contactors or relays. Verify the ampere rating (7 A) and ensure the terminal connection (screw clamp) fits your wiring.
