EATON Toggle Switch: 3 Position, 4 Connections, DPST, Screw Terminals Connection - Panel-Mount Toggle Switches
EATONPanel-Mount Toggle Switches

EATON Toggle Switch: 3 Position, 4 Connections, DPST, Screw Terminals Connection

The EATON 7500 Series Toggle Switch (MPN 7560K5) is a panel-mount, 3-position DPST switch with an On/None/Off configuration. It features a 10 A @ 250 V AC contact rating and 3/4 hp @ 250V AC horsepower rating, with…

SKU 3G-OTH-34051

Brand
EATON
Item
Toggle Switch: 3 Position, 4 Connections, DPST, Screw Terminals Connection
Category
Panel-Mount Toggle Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
7560K5
Series
7500
Type
DPST, Screw Terminals Connection
Horsepower
3/4 hp @ 250V AC
Connections
4
AC Contact Rating
10 A @ 250 V
Switch Function Configuration
On/None/Off
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON 7500 Series Toggle Switch (MPN 7560K5) is a panel-mount, 3-position DPST switch with an On/None/Off configuration. It features a 10 A @ 250 V AC contact rating and 3/4 hp @ 250V AC horsepower rating, with screw terminal connections and 4 connections.

Frequently Asked Questions

What is the EATON 7560K5 toggle switch used for?

The EATON 7560K5 is a panel-mount DPST toggle switch used for industrial on/off control of motors and equipment. Its 3/4 hp @ 250V AC rating makes it suitable for small machinery, pumps, and conveyors where a maintained Off position is required.

What are the specifications of the EATON 7560K5 toggle switch?

The EATON 7560K5 is a 3-position DPST switch with On/None/Off configuration. It has a 10 A @ 250 V AC contact rating, 3/4 hp @ 250V AC horsepower rating, and 4 screw terminal connections. It is part of the EATON 7500 Series.

Where to buy the EATON 7560K5 toggle switch worldwide?

3G Electric supplies the EATON 7560K5 toggle switch worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the EATON 7560K5 toggle switch?

Mount the EATON 7560K5 into a standard panel cutout and secure with the provided nut. Connect wires to the screw terminals per your circuit diagram, ensuring the switch is rated for your load. Always disconnect power before installation.
