EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded - Cylindrical Sensors with Built-in Connectors
EATONCylindrical Sensors with Built-in Connectors

EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded

The EATON Inductive Cylindrical Proximity Sensor (SKU 2XCT7) is a cylindrical sensor with a built-in connector, unshielded, with 3 wires and a 4-pin M12 connector. It operates on a DC supply voltage rating of 6-48V…

SKU 3G-OTH-35696

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded
Category
Cylindrical Sensors with Built-in Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E57-18LE20-B1D
Type
Unshielded
Wires
3
Pin M12
4 -
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
6-48V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor (SKU 2XCT7) is a cylindrical sensor with a built-in connector, unshielded, with 3 wires and a 4-pin M12 connector. It operates on a DC supply voltage rating of 6-48V DC and is not rated for AC supply voltage.

Frequently Asked Questions

What is the EATON inductive cylindrical proximity sensor used for?

This EATON sensor detects metallic objects without physical contact in industrial automation. It is commonly used for position sensing, part detection, and conveyor monitoring in manufacturing, packaging, and material handling applications.

What are the specifications of the EATON E57-18LE20-B1D proximity sensor?

The EATON E57-18LE20-B1D is an inductive cylindrical proximity sensor with a built-in 4-pin M12 connector. It is unshielded, has 3 wires, and operates on a DC supply voltage of 6-48V DC. It is not rated for AC supply voltage.

Where to buy the EATON E57-18LE20-B1D proximity sensor worldwide?

3G Electric supplies the EATON E57-18LE20-B1D proximity sensor worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the EATON inductive proximity sensor?

Mount the sensor securely using the built-in M12 connector. Connect the 3 wires per the wiring diagram: typically brown for DC+, blue for DC-, and black for the output. Ensure the DC supply voltage is within 6-48V DC. Avoid overtightening the connector.
