EATON Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Shielded - Cylindrical Sensors with Non-Terminated Cables
EATONCylindrical Sensors with Non-Terminated Cables

EATON Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Shielded

The EATON Inductive Cylindrical Proximity Sensor (SKU 2XDK6) is a shielded, non-terminated cable cylindrical sensor with 3 wires and a normally open (NO) output. It operates on a DC supply voltage rating of 6-48V DC…

SKU 3G-OTH-37511

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Shielded
Category
Cylindrical Sensors with Non-Terminated Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E59-M30A115C02-D1
Type
Shielded, NO
DC
6-48V
Wires
3
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
6-48V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor (SKU 2XDK6) is a shielded, non-terminated cable cylindrical sensor with 3 wires and a normally open (NO) output. It operates on a DC supply voltage rating of 6-48V DC and is not rated for AC supply voltage. This sensor is identified by manufacturer part number E59-M30A115C02-D1.

Frequently Asked Questions

What is the EATON E59-M30A115C02-D1 inductive proximity sensor used for?

The EATON E59-M30A115C02-D1 is a shielded inductive proximity sensor used for non-contact detection of metal objects in industrial automation, such as position sensing, part counting, and conveyor monitoring. It operates on 6-48V DC with a normally open output, making it suitable for PLC and control system inputs.

What are the specifications of the EATON E59-M30A115C02-D1 sensor?

The EATON E59-M30A115C02-D1 is a shielded cylindrical proximity sensor with a non-terminated cable, 3 wires, and normally open (NO) output. It has a DC supply voltage rating of 6-48V DC and is not rated for AC supply voltage. The manufacturer part number is E59-M30A115C02-D1.

Where to buy the EATON E59-M30A115C02-D1 sensor worldwide?

3G Electric supplies the EATON E59-M30A115C02-D1 inductive proximity sensor worldwide. As a global industrial equipment distributor established in 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the EATON E59-M30A115C02-D1 proximity sensor?

To install the EATON E59-M30A115C02-D1, mount the shielded sensor in a metal environment without derating. Connect the 3 wires: brown to 6-48V DC positive, blue to negative, and black as the normally open output. Ensure the sensing face is unobstructed and tighten the mounting nut securely.
