EATON Photoelectric Sensor: M18 Threaded, Non-Terminated Cable, 10-30V DC - Rectangular Sensors with Non-Terminated Cables
EATONRectangular Sensors with Non-Terminated Cables

EATON Photoelectric Sensor: M18 Threaded, Non-Terminated Cable, 10-30V DC

The EATON E65 SM Series photoelectric sensor is a rectangular sensor with a non-terminated cable, featuring an M18 threaded body made of resin. It operates on a 10-30V DC supply voltage and supports both NPN and PNP…

SKU 3G-OTH-34015

Brand
EATON
Item
Photoelectric Sensor: M18 Threaded, Non-Terminated Cable, 10-30V DC
Category
Rectangular Sensors with Non-Terminated Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E65-SMPP050-HD
Series
E65 SM
Type
Non-Terminated Cable, NPN and PNP
DC
10-30V
Body Material
Resin
Electrical Connection
Bare Wire
NEMA Enclosure Rating
6P
Nominal Sensor Diameter
M18 Threaded
DC Supply Voltage Rating
10-30V DC
Electrical Installation Type
Prewired Cable
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON E65 SM Series photoelectric sensor is a rectangular sensor with a non-terminated cable, featuring an M18 threaded body made of resin. It operates on a 10-30V DC supply voltage and supports both NPN and PNP outputs, with a bare-wire electrical connection and prewired cable installation. The sensor carries a NEMA 6P enclosure rating, making it suitable for demanding environments.

Frequently Asked Questions

What is the EATON E65-SMPP050-HD photoelectric sensor used for?

The EATON E65-SMPP050-HD is a rectangular photoelectric sensor with an M18 threaded resin body, used for object detection in industrial automation. It suits demanding environments thanks to its NEMA 6P rating, and its dual NPN/PNP output and 10-30V DC supply make it versatile for PLC and control system integration.

What are the specifications of the EATON E65-SMPP050-HD?

The EATON E65-SMPP050-HD is a 10-30V DC photoelectric sensor from the E65 SM series. It features a resin body, M18 threaded design, bare-wire electrical connection, and prewired cable. It supports both NPN and PNP outputs and carries a NEMA 6P enclosure rating for washdown and outdoor use.

Where to buy the EATON E65-SMPP050-HD worldwide?

You can source the EATON E65-SMPP050-HD photoelectric sensor from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine EATON components for your automation needs.

How to install the EATON E65-SMPP050-HD photoelectric sensor?

Mount the EATON E65-SMPP050-HD using its M18 threaded body and secure with a locknut. Connect the bare wires to a 10-30V DC power source and your controller, observing polarity for NPN or PNP output. Ensure the sensor face is clean and aligned with the target. The prewired cable simplifies installation in tight spaces.
