EATON Cordset: 1"-16 Female Straight x Bare Wire, 3 Pins, Yellow, PVC, 2 m Cable Lg - Single-Ended Cordsets
EATONSingle-Ended Cordsets

EATON Cordset: 1"-16 Female Straight x Bare Wire, 3 Pins, Yellow, PVC, 2 m Cable Lg

The EATON Cordset is a single-ended cordset with a 1"-16 Female Straight x Bare Wire connector, 3 pins, and a 2 m yellow PVC cable. It features a 16 AWG wire size, an IP67 rating, and a maximum current of 4 A.

SKU 3G-OTH-46789

Brand
EATON
Item
Cordset: 1"-16 Female Straight x Bare Wire, 3 Pins, Yellow, PVC, 2 m Cable Lg
Category
Single-Ended Cordsets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
CSAS3F3CY2202
Type
Yellow, PVC
Pins
3
Cable Lg
2 m
IP Rating
IP67
Wire Size
16 AWG
Max Current (A)
4 A
Cable Jacket Color
Yellow
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Cordset is a single-ended cordset with a 1"-16 Female Straight x Bare Wire connector, 3 pins, and a 2 m yellow PVC cable. It features a 16 AWG wire size, an IP67 rating, and a maximum current of 4 A.

Frequently Asked Questions

What is the EATON CSAS3F3CY2202 cordset used for?

The EATON CSAS3F3CY2202 is a single-ended cordset used to connect sensors, actuators, and industrial devices in automation and control systems. Its IP67 rating and yellow PVC jacket make it suitable for harsh environments requiring reliable signal or power transmission.

What are the specifications of the EATON CSAS3F3CY2202 cordset?

The EATON CSAS3F3CY2202 cordset has 3 pins, a 1"-16 female straight connector with bare wire termination, 2 m cable length, 16 AWG wire size, 4 A max current, IP67 rating, and a yellow PVC jacket. It is manufactured by EATON under MPN CSAS3F3CY2202.

Where to buy the EATON CSAS3F3CY2202 cordset worldwide?

You can source the EATON CSAS3F3CY2202 cordset through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive genuine EATON components for your automation needs.

How to select the right EATON cordset for an application?

To select the right EATON cordset, match pin count, connector thread (e.g., 1"-16), cable length, wire gauge, and current rating to your device requirements. For the CSAS3F3CY2202, ensure your application needs 3 pins, 4 A max, and IP67 protection. Consult 3G Electric for guidance.
