EATON Illuminated Push Button: Illuminated, Extended Profile, Metallic, 30 mm
The EATON Illuminated Push Button is an illuminated extended-length push button from the HT800 series, featuring a momentary action and a metallic push button material. This 30 mm device includes a 1NO contact…
SKU 3G-OTH-34305
Need installation or engineering help?
Ask a question
Product Description
The EATON Illuminated Push Button is an illuminated extended-length push button from the HT800 series, featuring a momentary action and a metallic push button material. This 30 mm device includes a 1NO contact configuration (MPN HT8GBAAF7).
Frequently Asked Questions
What is the EATON Illuminated Push Button used for?
The EATON Illuminated Push Button is used for industrial control panel applications requiring momentary switching with visual indication. Its 30 mm metallic extended profile suits heavy-duty environments like manufacturing lines, process plants, and machinery control stations where operators need clear illuminated status feedback.
What are the specifications of the EATON HT8GBAAF7 push button?
The EATON HT8GBAAF7 is a momentary illuminated push button from the HT800 series. It features a metallic push button material, extended profile design, 30 mm mounting size, and 1NO contact configuration. The device provides visual indication through integral illumination, suitable for industrial control systems.
Where to buy the EATON HT8GBAAF7 push button worldwide?
3G Electric supplies the EATON HT8GBAAF7 illuminated push button worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to any international destination. Contact our team to source this HT800 series momentary push button for your project.
How to install the EATON illuminated push button?
Install the EATON HT8GBAAF7 by mounting it in a 30 mm panel cutout, securing with the provided lock washer and nut. Wire the 1NO contact according to your control circuit schematic, ensuring proper voltage for the integral illumination. Follow standard industrial push button installation practices for reliable operation.
