EATON Illuminated Push Button: Illuminated, Extended Profile, Metallic, 30 mm
The EATON Illuminated Extended-Length Push Button (MPN 10250T76G) is a momentary-action, metallic push button from the 10250T series. This 30 mm illuminated device features a 1NO/1NC contact configuration with an…
SKU 3G-OTH-32196
Need installation or engineering help?
Ask a question
Product Description
The EATON Illuminated Extended-Length Push Button (MPN 10250T76G) is a momentary-action, metallic push button from the 10250T series. This 30 mm illuminated device features a 1NO/1NC contact configuration with an extended profile.
Frequently Asked Questions
What is the EATON 10250T76G illuminated push button used for?
The EATON 10250T76G is a momentary-action, illuminated push button used for industrial control panel signaling and machine operation. Its extended profile and metallic construction suit harsh environments requiring durable, visible operator input. Common applications include manufacturing lines, process control, and heavy machinery where reliable 1NO/1NC switching is needed.
What are the specifications of the EATON 10250T76G push button?
The EATON 10250T76G is a 30 mm metallic push button from the 10250T series. It features momentary action, an illuminated extended profile, and a 1NO/1NC contact configuration. The push button material is metallic, and the manufacturer part number is 10250T76G. It is designed for industrial control applications requiring durable, visible switching.
Where to buy the EATON 10250T76G push button worldwide?
You can source the EATON 10250T76G illuminated push button worldwide through 3G Electric. As a global industrial equipment distributor established in 1990, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact 3G Electric for availability and lead time on this EATON 10250T series component.
How to install the EATON 10250T76G illuminated push button?
Install the EATON 10250T76G by mounting it in a 30 mm panel cutout and securing it with the provided locknut. Wire the 1NO/1NC contacts according to your control circuit, ensuring proper voltage for the illumination. Follow standard industrial safety practices: de-energize circuits before installation and torque connections to manufacturer recommendations.
