EATON Pilot Light: 30 mm Panel Mounting Size, Yellow, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Pilot Light: 30 mm Panel Mounting Size, Yellow, LED

The EATON Pilot Light is a 30 mm panel-mounting-size LED pilot light from the Series 10250T. It features a yellow LED with a maximum supply voltage rating of 120 V AC and does not include a push-to-test function.

SKU 3G-OTH-34788

Brand
EATON
Item
Pilot Light: 30 mm Panel Mounting Size, Yellow, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
10250T197LYP2A
Series
10250T
Type
Yellow, LED
Includes Push-To-Test
No Push-To-Test Included
AC Max Volt Rating (Supply)
120 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Pilot Light is a 30 mm panel-mounting-size LED pilot light from the Series 10250T. It features a yellow LED with a maximum supply voltage rating of 120 V AC and does not include a push-to-test function.

Frequently Asked Questions

What is the EATON 10250T197LYP2A pilot light used for?

The EATON 10250T197LYP2A is a 30 mm panel-mounting-size LED pilot light used to indicate machine status or power-on condition in industrial control panels. Its yellow LED provides clear visual feedback at 120 V AC, making it suitable for manufacturing, processing, and automation environments.

What are the specifications of the EATON 10250T197LYP2A pilot light?

The EATON 10250T197LYP2A is a yellow LED pilot light from the Series 10250T. It has a 30 mm panel mounting size, a maximum supply voltage rating of 120 V AC, and does not include a push-to-test function. The manufacturer part number is 10250T197LYP2A.

Where to buy the EATON 10250T197LYP2A pilot light worldwide?

3G Electric supplies the EATON 10250T197LYP2A pilot light to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this EATON Series 10250T component.

How to install the EATON 10250T197LYP2A pilot light?

Install the EATON 10250T197LYP2A pilot light by mounting it in a 30 mm panel cutout and securing it with the provided locknut. Connect the supply wires to the LED terminals, ensuring the voltage does not exceed 120 V AC. Always follow standard industrial electrical safety practices and consult the product datasheet.
