EATON Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Extended Lever - Selector Switches
EATONSelector Switches

EATON Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Extended Lever

The EATON 10250T22LB is a 30 mm panel-mount selector switch from the 10250T Series, featuring a three-position maintained action with a long-handled polymer knob and a metallic bezel. It is rated for AC contacts at…

SKU 3G-OTH-35954

Brand
EATON
Item
Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Extended Lever
Category
Selector Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
10250T22LB
Series
10250T
Type
Extended Lever, 2NO/2NC, Metallic
Cam
3
Action
Maintained/Maintained/Maintained
Positions
3
AC Contact Rating
10 A @ 600 V
DC Contact Rating
5 A @ 250 V
Operator Head Type
Long-Handled Knob
Operator Illumination
Non-Illuminated
Operator Head Material
Polymer
Switch Bezel Material Type
Metallic
Switch Function @ 1st Position
On
Switch Function @ 2nd Position
On
Switch Function @ 3rd Position
On
Switch Function @ 4th Position
No Fourth Position
Hazardous Location Specification
Not Rated
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON 10250T22LB is a 30 mm panel-mount selector switch from the 10250T Series, featuring a three-position maintained action with a long-handled polymer knob and a metallic bezel. It is rated for AC contacts at 10 A @ 600 V and DC contacts at 5 A @ 250 V, with a Cam 3 configuration and non-illuminated operation. This switch provides On/On/On functionality across its three positions and is not rated for hazardous locations.

Frequently Asked Questions

What is the EATON 10250T22LB selector switch used for?

The EATON 10250T22LB is a 30 mm panel-mount selector switch used for industrial control applications requiring three-position maintained On/On/On action. It is suitable for machinery control panels, conveyor systems, and process equipment where operators need to select between multiple operational states.

What are the specifications of the EATON 10250T22LB selector switch?

The EATON 10250T22LB is a 30 mm panel-mount selector switch with three maintained positions, extended lever, and 2NO/2NC contacts. It has an AC contact rating of 10 A @ 600 V and DC rating of 5 A @ 250 V. The polymer operator head features a long-handled knob with metallic bezel, non-illuminated, and is not rated for hazardous locations.

Where to buy the EATON 10250T22LB selector switch worldwide?

3G Electric supplies the EATON 10250T22LB selector switch worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to any destination. Contact us for availability and lead time; we source and deliver this EATON 10250T Series switch globally.

How to install the EATON 10250T22LB selector switch?

Install the EATON 10250T22LB by mounting it in a 30 mm panel cutout and securing with the provided locknut. Wire the 2NO/2NC contacts according to your control circuit, ensuring the AC rating of 10 A @ 600 V or DC rating of 5 A @ 250 V is not exceeded. The maintained action holds each of the three positions without spring return.
