EATON Extended Push Button: 30 mm, Non-Metallic - Extended-Length Push-Button Operators
EATONExtended-Length Push-Button Operators

EATON Extended Push Button: 30 mm, Non-Metallic

The EATON Extended Push Button is a 30 mm, non-metallic, momentary push-button operator from the 10250T series. This extended-length operator features a momentary action and is constructed with non-metallic…

SKU 3G-OTH-31896

Brand
EATON
Item
Extended Push Button: 30 mm, Non-Metallic
Category
Extended-Length Push-Button Operators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
10250T503
Series
10250T
Action
Momentary
Push Button Material Type
Non-Metallic
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Extended Push Button is a 30 mm, non-metallic, momentary push-button operator from the 10250T series. This extended-length operator features a momentary action and is constructed with non-metallic materials. It is designed for industrial control panel applications requiring a durable, non-conductive operator interface.

Frequently Asked Questions

What is the EATON 10250T503 extended push button used for?

The EATON 10250T503 is a 30 mm, non-metallic, momentary push-button operator used in industrial control panels. It provides a durable, non-conductive interface for momentary switching actions in manufacturing, processing, and automation environments where operator safety and reliability are critical.

What are the specifications of the EATON 10250T503 push button?

The EATON 10250T503 is a 30 mm extended-length push-button operator from the 10250T series. It features momentary action and a non-metallic push button material. The manufacturer part number is 10250T503, and it is designed for industrial control panel applications requiring a non-conductive operator interface.

Where to buy the EATON 10250T503 push button worldwide?

3G Electric supplies the EATON 10250T503 extended push button worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this EATON 10250T503 component to any country.

How to install the EATON 10250T503 momentary push button?

Install the EATON 10250T503 in a 30 mm panel cutout using the provided mounting hardware. Ensure the non-metallic operator is securely fastened and the momentary action is tested before use. Follow standard industrial control panel wiring practices and consult the EATON 10250T series manual for torque and clearance specifications.
