EATON Pilot Light: 30 mm Panel Mounting Size, Green, LED - LED Pilot-Lights
EATONLED Pilot-Lights

EATON Pilot Light: 30 mm Panel Mounting Size, Green, LED

The EATON Pilot Light is a 30 mm panel-mounting-size LED pilot light from the E34 series. It features a green LED with a maximum supply voltage rating of 120 V AC and does not include a push-to-test function.

SKU 3G-OTH-33697

Brand
EATON
Item
Pilot Light: 30 mm Panel Mounting Size, Green, LED
Category
LED Pilot-Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E34FB197LGP2A
Series
E34
Type
Green, LED
Includes Push-To-Test
No Push-To-Test Included
AC Max Volt Rating (Supply)
120 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Pilot Light is a 30 mm panel-mounting-size LED pilot light from the E34 series. It features a green LED with a maximum supply voltage rating of 120 V AC and does not include a push-to-test function.

Frequently Asked Questions

What is the EATON E34FB197LGP2A pilot light used for?

The EATON E34FB197LGP2A is a 30 mm panel-mounting LED pilot light used as a visual status indicator on industrial control panels, machinery, and switchgear. Its green LED signals normal operation or power-on status in applications requiring a 120 V AC supply.

What are the specifications of the EATON E34FB197LGP2A pilot light?

The EATON E34FB197LGP2A is a green LED pilot light from the E34 series with a 30 mm panel mounting size. It has a maximum supply voltage rating of 120 V AC and does not include a push-to-test function. The manufacturer part number is E34FB197LGP2A.

Where to buy the EATON E34FB197LGP2A pilot light worldwide?

You can source the EATON E34FB197LGP2A pilot light through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the EATON E34FB197LGP2A pilot light?

To install the EATON E34FB197LGP2A, mount it in a 30 mm panel cutout and secure it with the provided locking ring. Connect the supply wires to the LED terminals, ensuring the voltage does not exceed 120 V AC. Follow standard industrial wiring practices and verify polarity if required.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas
