EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Shielded, 3 Wires - Cylindrical Sensors with Built-in Connectors
EATONCylindrical Sensors with Built-in Connectors

EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Shielded, 3 Wires

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HX41, MPN E57G-18SPN5-Q) is a shielded cylindrical sensor with a built-in connector, featuring 3 wires and a 4-pin micro connector. It operates on a DC supply…

SKU 3G-OTH-35813

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Built-in Connector, Shielded, 3 Wires
Category
Cylindrical Sensors with Built-in Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E57G-18SPN5-Q
Type
Shielded
Wires
3
Pin Micro
4 -
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
10-30V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HX41, MPN E57G-18SPN5-Q) is a shielded cylindrical sensor with a built-in connector, featuring 3 wires and a 4-pin micro connector. It operates on a DC supply voltage rating of 10-30V DC and is not rated for AC supply voltage.

Frequently Asked Questions

What is the EATON E57G-18SPN5-Q inductive proximity sensor used for?

The EATON E57G-18SPN5-Q inductive cylindrical proximity sensor detects metallic objects without contact. It is used in industrial automation for position sensing, part detection, and machine control across machining, material handling, and packaging applications.

What are the specifications of the EATON E57G-18SPN5-Q proximity sensor?

The EATON E57G-18SPN5-Q is a shielded cylindrical sensor with a built-in 4-pin micro connector and 3 wires. It operates on a DC supply voltage of 10-30V DC and is not rated for AC supply. The MPN is E57G-18SPN5-Q.

Where to buy the EATON E57G-18SPN5-Q proximity sensor worldwide?

3G Electric supplies the EATON E57G-18SPN5-Q inductive proximity sensor worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the EATON E57G-18SPN5-Q shielded proximity sensor?

Mount the EATON E57G-18SPN5-Q sensor in a non-ferrous bracket to avoid interference. Connect the 4-pin micro connector to a compatible DC power supply (10-30V DC). Ensure the sensing face is unobstructed and the shielded housing is grounded per manufacturer guidelines.
