EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded - Cylindrical Sensors with Built-in Connectors
EATONCylindrical Sensors with Built-in Connectors

EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HX59, MPN E57G-12UPN4-Q) is a cylindrical sensor with a built-in connector, unshielded, with 3 wires and a 4-pin micro connector. It operates on a DC supply…

SKU 3G-OTH-34797

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded
Category
Cylindrical Sensors with Built-in Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E57G-12UPN4-Q
Type
Unshielded
Wires
3
Pin Micro
4 -
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
10-30V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HX59, MPN E57G-12UPN4-Q) is a cylindrical sensor with a built-in connector, unshielded, with 3 wires and a 4-pin micro connector. It operates on a DC supply voltage rating of 10-30V DC and is not rated for AC supply voltage.

Frequently Asked Questions

What is the EATON inductive cylindrical proximity sensor used for?

The EATON E57G-12UPN4-Q inductive proximity sensor detects metallic objects without contact. It is used in industrial automation for position sensing, part counting, and machine control in harsh environments.

What are the specifications of the EATON E57G-12UPN4-Q proximity sensor?

This EATON sensor is unshielded, has 3 wires, and a 4-pin micro built-in connector. It operates on 10-30V DC supply voltage and is not rated for AC. The MPN is E57G-12UPN4-Q, and it is a cylindrical inductive proximity sensor.

Where to buy the EATON E57G-12UPN4-Q proximity sensor worldwide?

You can source the EATON E57G-12UPN4-Q from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to install the EATON inductive cylindrical proximity sensor?

Mount the sensor securely with the sensing face toward the target. Connect the 4-pin micro connector to a compatible cable, ensuring 10-30V DC power. Maintain a gap from metal objects to avoid interference, as it is unshielded.
