EATON Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Unshielded - Cylindrical Sensors with Non-Terminated Cables
EATONCylindrical Sensors with Non-Terminated Cables

EATON Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Unshielded

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HX66, MPN E57G-30UPN15-C2) is a non-terminated cable cylindrical sensor from EATON. It is unshielded, operates on 3 wires, and has a DC supply voltage rating of…

SKU 3G-OTH-38782

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Unshielded
Category
Cylindrical Sensors with Non-Terminated Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E57G-30UPN15-C2
Type
Unshielded
DC
10-30V
Wires
3
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
10-30V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HX66, MPN E57G-30UPN15-C2) is a non-terminated cable cylindrical sensor from EATON. It is unshielded, operates on 3 wires, and has a DC supply voltage rating of 10-30V DC. The AC supply voltage rating is not rated.

Frequently Asked Questions

What is the EATON E57G-30UPN15-C2 inductive proximity sensor used for?

The EATON E57G-30UPN15-C2 is an unshielded cylindrical proximity sensor used for non-contact detection of metal objects in industrial automation, packaging, and material handling applications. It operates on 10-30V DC with 3 wires and a non-terminated cable for flexible installation.

What are the specifications of the EATON E57G-30UPN15-C2 sensor?

The EATON E57G-30UPN15-C2 is an unshielded inductive proximity sensor with a DC supply voltage rating of 10-30V DC. It has 3 wires, a non-terminated cable, and is not rated for AC supply voltage. The manufacturer part number is E57G-30UPN15-C2.

Where to buy the EATON E57G-30UPN15-C2 proximity sensor worldwide?

3G Electric supplies the EATON E57G-30UPN15-C2 proximity sensor worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this sensor along with other EATON automation components.

How to install the EATON E57G-30UPN15-C2 unshielded proximity sensor?

Mount the EATON E57G-30UPN15-C2 sensor securely with the sensing face unobstructed. Connect the 3 wires (typically brown for 10-30V DC, blue for ground, black for output) to your controller. Ensure the DC supply voltage is within 10-30V DC. Avoid metal debris near the unshielded face.
