EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded - Cylindrical Sensors with Built-in Connectors
EATONCylindrical Sensors with Built-in Connectors

EATON Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded

The EATON Inductive Cylindrical Proximity Sensor with Built-in Connector (MPN E57G-18UNC8-Q) is an unshielded, 3-wire cylindrical sensor featuring a 4-pin Micro connector. It operates on a DC supply voltage rating of…

SKU 3G-OTH-35802

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Built-in Connector, Unshielded
Category
Cylindrical Sensors with Built-in Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E57G-18UNC8-Q
Type
Unshielded
Wires
3
Pin Micro
4 -
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
10-30V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor with Built-in Connector (MPN E57G-18UNC8-Q) is an unshielded, 3-wire cylindrical sensor featuring a 4-pin Micro connector. It operates on a DC supply voltage rating of 10-30V DC and is not rated for AC supply voltage.

Frequently Asked Questions

What is the EATON E57G-18UNC8-Q inductive proximity sensor used for?

The EATON E57G-18UNC8-Q inductive cylindrical proximity sensor detects metallic objects without contact. It is commonly used in industrial automation for position sensing, part detection, and machine control in manufacturing, packaging, and material handling applications.

What are the specifications of the EATON E57G-18UNC8-Q proximity sensor?

The EATON E57G-18UNC8-Q is an unshielded, 3-wire cylindrical sensor with a built-in 4-pin Micro connector. It operates on a DC supply voltage of 10-30V DC and is not rated for AC supply. The manufacturer part number is E57G-18UNC8-Q.

Where to buy the EATON E57G-18UNC8-Q proximity sensor worldwide?

You can source the EATON E57G-18UNC8-Q proximity sensor through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the EATON E57G-18UNC8-Q inductive proximity sensor?

Mount the sensor securely in a non-ferrous bracket to avoid interference. Connect the 4-pin Micro connector to a compatible DC power supply (10-30V DC). Ensure the sensing face is unobstructed and the target material is metallic. Follow standard wiring diagrams for 3-wire DC sensors.
