EATON Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Shielded - Cylindrical Sensors with Non-Terminated Cables
EATONCylindrical Sensors with Non-Terminated Cables

EATON Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Shielded

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HY02, MPN E57PS-18SPC5-C2) is a shielded, non-terminated cable cylindrical sensor with 3 wires and a normally closed (NC) output. It operates on a DC supply…

SKU 3G-OTH-38385

Brand
EATON
Item
Inductive Cylindrical Proximity Sensor: Non-Terminated Cable, Shielded
Category
Cylindrical Sensors with Non-Terminated Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
E57PS-18SPC5-C2
Type
Shielded, NC
DC
10-48V
Wires
3
AC Supply Voltage Rating
Not Rated
DC Supply Voltage Rating
10-48V DC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Inductive Cylindrical Proximity Sensor (SKU 40HY02, MPN E57PS-18SPC5-C2) is a shielded, non-terminated cable cylindrical sensor with 3 wires and a normally closed (NC) output. It operates on a DC supply voltage rating of 10-48V DC and is not rated for AC supply voltage.

Frequently Asked Questions

What is the EATON E57PS-18SPC5-C2 inductive proximity sensor used for?

The EATON E57PS-18SPC5-C2 is a shielded cylindrical proximity sensor used for non-contact detection of metal objects in industrial automation, packaging, and material handling. Its normally closed (NC) output and 10-48V DC rating suit machine safety and position-sensing applications.

What are the specifications of the EATON E57PS-18SPC5-C2?

The EATON E57PS-18SPC5-C2 is a shielded inductive proximity sensor with a non-terminated cable, 3 wires, and normally closed (NC) output. It operates on 10-48V DC and is not rated for AC supply voltage. The manufacturer part number is E57PS-18SPC5-C2.

Where to buy the EATON E57PS-18SPC5-C2 worldwide?

You can source the EATON E57PS-18SPC5-C2 from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the EATON E57PS-18SPC5-C2 proximity sensor?

Mount the shielded sensor in a metal-free zone to avoid interference. Connect the 3 wires to a 10-48V DC supply per the wiring diagram: typically brown for V+, blue for V-, and black for NC output. Ensure the sensing face is unobstructed and tighten the mounting nut securely.
