EATON Combination Starter: Fusible Disconnect, 3 Poles, NEMA Size 1, 240V AC

The EATON NEMA Combination Starter (MPN ECN1608EAB-R63/CL30) is used for motor control and protection in industrial applications. It combines a fusible disconnect switch with an electronic overload relay, providing overcurrent protection and switching for three-phase motors up to 600V AC. Common in manufacturing, HVAC, and pumping systems.

This Freedom series starter is a three-phase, NEMA Size 1 unit with a 220/240V AC coil voltage and 600V AC maximum voltage rating. It accepts Class R fuses, includes a pilot light and auxiliary contacts, uses screw terminals, and requires no thermal units due to its electronic overload design. The enclosure is NEMA-rated 1.

3G Electric supplies the EATON NEMA Combination Starter (ECN1608EAB-R63/CL30) worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this EATON Freedom series starter to any country.

Select based on motor full-load current, voltage, and phase. This EATON Freedom starter is NEMA Size 1, suitable for motors up to 3 HP at 240V AC or 7.5 HP at 480V AC. Ensure coil voltage matches your control circuit (220/240V AC here) and that Class R fuses are used. The electronic overload eliminates thermal unit selection.
