EATON Combination Starter: Fusible Disconnect, 3 Poles, NEMA Size 4 - Fusible Starters with Electronic Overloads
EATONFusible Starters with Electronic Overloads

EATON Combination Starter: Fusible Disconnect, 3 Poles, NEMA Size 4

The EATON NEMA Combination Starter: Fusible Disconnect (MPN ECN1642BAH-R63/FL30) is a three-phase, 3-pole fusible starter with an electronic overload, part of the Freedom series. It features a 240V AC coil voltage, a…

SKU 3G-OTH-41506

Brand
EATON
Item
Combination Starter: Fusible Disconnect, 3 Poles, NEMA Size 4
Category
Fusible Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
ECN1642BAH-R63/FL30
Series
Freedom
Type
NEMA Size 4, Electronic Protection
Phase
Three
Poles
3
Poles/Phase
3 Pole / Three Phase
Coil Voltage
240V AC
Operator Type
No Operator
For Fuse Class
Class R
Control Transformer
No
Includes Pilot Light
No
Maximum Voltage Rating
600V AC
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Terminals
Includes Auxiliary Contacts
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Combination Starter: Fusible Disconnect (MPN ECN1642BAH-R63/FL30) is a three-phase, 3-pole fusible starter with an electronic overload, part of the Freedom series. It features a 240V AC coil voltage, a maximum voltage rating of 600V AC, and accepts Class R fuses. This unit includes auxiliary contacts and screw terminals, with no operator, pilot light, or control transformer.

Frequently Asked Questions

What is the EATON NEMA Combination Starter ECN1642BAH-R63/FL30 used for?

This EATON Freedom series combination starter provides motor starting and overload protection in industrial applications. It integrates a fusible disconnect switch with electronic overload protection for three-phase motors up to 600V AC, suitable for heavy-duty machinery and process equipment.

What are the specifications of the EATON ECN1642BAH-R63/FL30?

This NEMA Size 4 starter has 3 poles, 240V AC coil voltage, 600V AC maximum rating, and accepts Class R fuses. It includes screw terminals and auxiliary contacts but no operator, pilot light, or control transformer. Electronic overload protection eliminates the need for thermal units.

Where to buy the EATON ECN1642BAH-R63/FL30 worldwide?

3G Electric supplies the EATON ECN1642BAH-R63/FL30 NEMA combination starter to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time.

How to select the correct EATON NEMA combination starter for a motor?

Match the starter's NEMA size to the motor's full-load current and horsepower rating. Verify coil voltage matches your control circuit (240V AC for this model). Ensure the disconnect fuse class (Class R) and maximum voltage rating (600V AC) meet your system requirements. Consult EATON documentation for exact sizing.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON fusible starters with electronic overloads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
